Jensen VM9726BT User Manual

88
VM9726BT
General
Auxiliary Input impedance: 10k
Power Supply: 11 to 16VDC, negative ground
Power Antenna (Blue): 500mA max, current limited protection
Amplier Remote (Blue/White): 500mA max, current limited protection
Operating Temperature: -20C ~ 65C
Fuse: 15-amp, mini ATO type
DIN chassis dimensions: 7” X 7” X 4” (178mm x 178mm x 100mm)
CEA Power Ratings
Power Output: 13 Watts RMS x 4 channels into 4-Ohms @ < 1%
THD+N
Signal to Noise Ratio: 70dBA below reference (Reference: 1 Watt,
4-Ohms)
Frequency Response: 20 Hz - 20 kHz, -3dB. (Aux Input used as
reference input)
Reference Supply Voltage: 14.4VDC
*Specications subject to change without notice

Jensen VM9726BT Specifications

General

Brand	Jensen
Model	VM9726BT
Category	Car Receiver
Language	English
