Jensen VX3518 - Product Specifications; CD, Tuner, and USB Specifications; Amplifier Power and Dimensions

33
VX3518 OPERATION
Specifications
Frequency response: 20Hz-20kHz
Channel separation @ 1kHz: >60dB
D/A converter: 1 Bit
Tuning range: 87.5MHz-107.9MHz
Usable sensitivity: 8.5dBf
50dB quieting sensitivity: 10dBf
Stereo separation @ 1kHz: >30dB
Frequency response: 30Hz-13kHz
Tuning range: 530kHz-1710kHz
Usable sensitivity: <42dBu
Frequency response: 30Hz-2.2kHz
USB Charge: 1A
Speaker output impedance: 4~8 ohms
Line output voltage: 4 Volts RMS
Dimensions: 7" x 7" x 2" (178 x 178 x 50 mm)
Design and specifications subject to change without notice.
CD Player
FM Tuner
AM Tuner
General
CEA-2006 Power Standard Specifications
(reference: 14.4VDC +/- 0.2V, 20Hz~20kHz)
Power Output: 16 Watts RMS x 4 channels at 4 ohms and < 1% THD+N
Signal to Noise Ratio: 80dBA (reference: 1 watt into 4 ohms)
