JessEm Tool MITE-R-SLIDE II User Manual

Suggested Router Bit Speedspeeds
Max. Speed
24,000 RPM
18,000 RPM
Bit DiameterBit Diameter
1” (25mm)
1-1/4” - 2” (30-50mm)
2-1/4” - 2-1/2” (55-65mm)
3
” - 3
-
1
/2” (75-90mm)
12,000 RPM
16,000 RPM
FIGURE A
3
ASSEMBLY OF THE MITE-R-SLIDE II
STEP 1: Remove all the contents from the Mite-R-Slide II Box.
STEP 2: Ensure you have all the subassemblies and pieces noted in the contents list on Page 3.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
PART # DESCRIPTION QTY PART # DESCRIPTION QTY
A 1 H 1
B 1 I 2
C 1 J 1
D 1 K 1
E 1 L 1
F 1 M 2
G
Mite-R-Slide II Gauge and Fence Assembly
Mite-R-Slide II Roller Assembly
Mite-R-Slide II Guard Mount Assembly
Knurled Handle
3/8" I.D. x 1" O.D. Stainless Steel Heavy Washer
Left Hand Roller Bumper
Right Hand Roller Bumper 1 N
Guard
10-24 x 3/8" button head machine screws
3/16" Hex Key
9/64" Hex Key
1/8" Hex Key
1/4-20 x 1" Stainless Steel Cap Screws
1/4" I.D. x 1" O.D. Stainless Steel Heavy Washer 2
SUB-ASSEMBLED PARTS LIST
