Jet J-8203K - Page 27

27
Index No Part No Description Size Qty
65 .............. 5782681 .................... Retaining Ring ......................................................... R35 .............................. 2
67 .............. 5783091 .................... Flat Head Screw ...................................................... M5x10 ........................... 4
68 .............. 5625121 .................... Hex Cap Screw ........................................................ M6x10 ........................... 2
69 .............. TS-1482021 .............. Hex Cap Screw ........................................................ M6x12 ........................... 6
70 .............. TS-1482041 .............. Hex Cap Screw ........................................................ M6x20 ........................... 1
72 .............. 5782761 .................... Pan Head Screw ...................................................... M5 x8 ............................. 1
73 .............. 5783141 .................... Hex Cap Bolt (Left Hand)......................................... M8x20 ........................... 1
74 .............. TS-1490051 .............. Hex Cap Screw ........................................................ M8x30 ........................... 2
75 .............. TS-1490071 .............. Hex Cap Bolt............................................................ M8x40 ........................... 4
76 .............. 5783551 .................... Hex Cap Screw ........................................................ M8x80 ........................... 1
77 .............. TS-1491081 .............. Hex Cap Bolt............................................................ M10x50 ......................... 2
78 .............. 5783051 .................... Hex Cap Bolt............................................................ M16x55 ......................... 1
79 .............. 5782641 .................... Pan Head Screw ...................................................... M5 x6 ............................. 2
80 .............. 5782871 .................... Pan Head Screw ...................................................... M5 x8 ........................... 12
81 .............. 5782961 .................... Pan Head Screw ...................................................... M5 x25 ........................... 3
82 .............. 5783131 .................... Pan Head Screw ...................................................... M6 x8 ............................. 4
83 .............. 5783331 .................... Set Screw ................................................................ M6x10 ........................... 7
84 .............. 5783361 .................... Micro Adjustment Screw .......................................... M8x35 ........................... 2
85 .............. 5783271 .................... Set Screw ................................................................ M10x10 ......................... 1
86 .............. 6286667 .................... Self Tapping Screw.................................................. M3.5x16 ........................ 2
87 .............. 5782941 .................... Self Tapping Screw.................................................. M4x8 ............................. 2
88 .............. TS-1550041 .............. Flat Washer ............................................................. M6 ................................. 2
89 .............. TS-1550041 .............. Flat Washer ............................................................. M6 ................................. 1
90 .............. 5783231 .................... Flat Washer ............................................................. M8 ................................. 8
91 .............. 5511747 .................... Flat Washer ............................................................. M8 ................................. 1
92 .............. 5783061 .................... Flat Washer ............................................................. M16 ............................... 2
93 .............. 5511752 .................... Lock Washer ........................................................... M8 ................................ 8
94 .............. 5511752 .................... Lock Washer ........................................................... M8 ................................ 2
97 .............. J-5782931G .............. Switch Bracket ......................................................... 1PH ............................... 1
.................. 141039 ...................... Switch Bracket ......................................................... 3PH ............................... 1
98 .............. TS-1482021 .............. Hex Cap Screw ........................................................ M6x12 .......................... 1
99 .............. 5782951 .................... Switch ...................................................................... 1Ph............................... 1
.................. 994507 ...................... Switch ...................................................................... 3Ph 480V ..................... 1
100 ............ 5782981 .................... Power Cord .............................................................. 115/230V, 1Ph ............. 1
.................. IC148005................... Power C ord .............................................................. 230/460V, 3Ph,600V ..... 1
102 ............ 5782971 .................... Strain Relief ............................................................. 6N-4, 1PH .................... 2
.................. 998630 ...................... Strain Relief ............................................................ 7P-2, 3PH .................... 2
103 ............ 5783021 .................... Wire Clip .................................................................. ...................................... 1
105 ............ 5782881 .................... Flange Nut ............................................................... M5 ................................ 4
106 ............ 5783431 .................... Flat Washer ............................................................. M6x13x1 ....................... 1
107 ............ AFS400-23 ................ Lock Washer, External Tooth .................................. M5 ................................. 2
112 ............ 5783671 .................... Spacing Sleeve ........................................................ ...................................... 1
113 ............ 5783641 .................... Adjusting Block ........................................................ ...................................... 1
114 ............ 5783651 .................... Guide Plate .............................................................. ..................................... 1
115 ............ 5783731 .................... Adjusting Bar ........................................................... ..................................... 1
116 ............ 5783711 .................... Adjusting Bar ........................................................... ..................................... 1
117 ............ 5783721 .................... Handle ..................................................................... ..................................... 2
118 ............ 5783681 .................... Setting Bushing........................................................ ...................................... 2
119 ............ 5783771 .................... Spacer .................................................................... ...................................... 2
121 ............ 5783751 .................... Flange Nut ............................................................... M8 ................................ 2
122 ............ TS-1514021 .............. Flat Head Socket Screw .......................................... M6x15 ........................... 2
123 ............ 5640181 .................... Set Screw ................................................................ M5x5 ............................. 4
124 ............ 5783761 .................... Wave Washer .......................................................... 8x13 ............................. 2
125 ............ 5784695 .................... Miter Gauge Assembly ............................................ ...................................... 1
126 ............ 5517184 .................... Pan Head Screw ...................................................... M4x25 ........................... 2
.................. JET-138..................... JET Logo (not shown).............................................. 138 x 57mm .................. 1
