Parts List – Saw Head – Models J-8201,J-8203,J-8201VS and J-8203VS
Index No Part No Description Size Qty
1 ................ J-5782511G .............. Upper Arm, Frame ................................................... ...................................... 1
2 ................ J-5873041G .............. Base......................................................................... ...................................... 1
3 ............... 5783241 .................... Dowel Pin................................................................. ...................................... 4
4 ................ 5782521 .................... Upper Wheel Sliding Bracket ................................... ...................................... 1
5 ................ 5782591 .................... Blade Tension Adjustment Knob ............................. ...................................... 1
6 ................ 5782611 .................... Tension Spring......................................................... ...................................... 1
7 ................ 5782571 .................... Blade Track Adjustment Knob ................................. M8x55 ........................... 1
8 ................ 5782541 .................... Pivot Pin................................................................... ...................................... 2
9 ................ 5782531 .................... Upper Wheel Hinge w/ Shaft ................................... ................................... 1
10............... J-5782631G ............... Inner Upper Wheel Guard ......................................... ...................................... 1
11 .............. 5782821 .................... Stud ......................................................................... ...................................... 2
12 .............. 5782741 .................... Fixed Bolt ................................................................. ..................................... 2
13 .............. 5782751 .................... Catch ....................................................................... ...................................... 2
14 .............. 170080 ...................... Stud Latch................................................................ ..................................... 2
15 .............. TS-1522021 .............. Set Screw ................................................................ M5x8 ............................ 2
16 .............. 5782831 .................... Blade Guard............................................................. ...................................... 1
17 .............. 5782841 .................... Retainer ................................................................... ..................................... 2
18 .............. J-5782891G .............. Outer Upper Wheel Guard ....................................... ...................................... 1
19 .............. 5782861 .................... Hinge (Upper) .......................................................... ...................................... 1
20 .............. 5782921 .................... Knob ........................................................................ M8 ............................... 2
21 .............. 5782661 .................... Upper Wheel ............................................................ ...................................... 1
22 .............. 5782691 .................... Wheel Protector ....................................................... ...................................... 2
24 .............. 5783161 .................... Lower Wheel ............................................................ ...................................... 1
25 .............. 141020 ...................... Saw Blade for Metal Cutting .................................... 93-1/2” x 14T/in ............. 1
.................. 170368 ...................... Saw Blade for Wood Cutting.................................... 93-1/2” x 6T/in. .............. 1
26 .............. J-5783111G .............. Lower Wheel Guard ................................................. ...................................... 1
27 .............. 5783121 .................... Dust Chute ............................................................... ...................................... 1
28 .............. 5783081 .................... Hinge (Lower) .......................................................... ...................................... 1
30 .............. 5783351 .................... Guide Post ............................................................... ...................................... 1
31 .............. 5783281 .................... Knob ........................................................................ M10x30 ......................... 1
32 .............. 5783261 .................... Spring ...................................................................... ...................................... 1
33 .............. SB-8MM .................... Steel Ball.................................................................. 8mm .............................. 1
34 .............. 5783421 .................... Upper Wheel Blade Guard....................................... ...................................... 1
35 .............. 5783341 .................... Upper Support Bracket Post .................................... ...................................... 1
36 .............. 5783411 .................... Support Bracket ....................................................... ...................................... 2
37 .............. 5783371 .................... Micro Adjustment Nut .............................................. ..................................... 2
38 .............. 5783321 .................... Upper Spacing Sleeve ............................................. ..................................... 2
39 .............. 5783391 .................... Carbide Blade Guide .............................................. ...................................... 4
40 .............. 5783631 .................... Lower Support Bracket Post ................................... ...................................... 1
42 .............. 5783591 .................... Bracket Trunnion Support ........................................ ...................................... 1
43 .............. 5783611 .................... Point......................................................................... ...................................... 1
44 .............. J-5783451G .............. Table ........................................................................ ..................................... 1
45 .............. 5783471 .................... Table Insert .............................................................. ..................................... 1
46 .............. 5783481 .................... Table Pin.................................................................. ..................................... 1
47 .............. 5783521 .................... Trunnion................................................................... ..................................... 2
48 .............. 5783531 .................... Scale ........................................................................ ..................................... 1
49 .............. 5783491 .................... Trunnion Clamp S hoe .............................................. ..................................... 2
50 .............. 5783621 .................... Knob ........................................................................ M10 .............................. 2
53 .............. 5782641 .................... Pan Head Screw ...................................................... M5 x6 ............................ 1
54 .............. 5783311 .................... Bearing .................................................................... 6200ZZ......................... 2
55 .............. BB-6202ZZ ................ Bearing .................................................................... 6202Z ........................... 2
56 .............. 5783171 .................... Bearing .................................................................... 6204LLU ...................... 1
57 .............. 5783211 .................... Key........................................................................... 5x5x20 .......................... 2
58 .............. 5782881 .................... Flange Nut ............................................................... M5 .............................. 12
59 .............. 5783581 .................... Hex Nut .................................................................... M8 ................................ 5
60 .............. 5625361 .................... Hex Nut .................................................................... M12 .............................. 1
61 .............. 5783071 .................... Hex Nut .................................................................... M16 ............................... 1
62 .............. 5782621 .................... Square Nut............................................................... ...................................... 1
63 .............. 5782581 .................... Wing Nut .................................................................. M8 ................................ 1
64 .............. 5783461 .................... Roll Pin ................................................................... 3x8 ............................... 1
