Unpacking
Open shipping container and check for shipping
damage. Report any damage immediately to
your distributor and shipping agent. Do not
discard any shipping material until the Mortiser
is assembled and running properly.
Compare the contents of your container with the
following parts list to make sure all parts are
intact. Missing parts, if any, should be reported
to your distributor. Read the instruction manual
thoroughly for assembly, maintenance and
safety instructions.
Contents of the Shipping Container
Box #1:
1 Mortiser (A)
1 Z-Axis Handle (B)
1 Work Stop Assembly (C)
1 Chuck Removal Wrench (D)
2 Handwheel Handles (E)
1 Chuck Key (F)
3 Chisel Bushings, 5/8, 3/4, 1-1/8 I.D. (G)
(NOTE: one is already installed)
1 Chuck Extension Adaptor (H)
1 Wood Table (J)
2 Flat Head Screws, M6x20 (K)
1 Owner's Manual (not shown)
1 Warranty Card (not shown)
Box #2:
1 Stand (L)
1 Package of fasteners (M):
4 Hex Cap Screws, M8x45
4 Lock Washers, M8
Figure 2
