8
5.0 Specifications
Table 1
Model number
JMS-10X JMS-12X
Stock number 707210 707212
Motor and Electricals
Motor type Series-wound, double insulated
Input power 1.7 kW
Phase single
Voltage 115 V
Cycle 60 Hz
Listed FLA (full load amps) 15 A
Motor speed 4000±10% RPM
Starting amps 25 A
Running amps (no load) 5.10 A 5.33±10% A
Switch Saw: 18A,127V; Laser: 6A 250AC; LED: 10A 125VAC
Power cable SJT 14AWGx3C, 8-1/2 ft.
Power plug Type ZT-1 (115V), without ground
Recommended circuit size
1
15 A
Sound emission
2
95 dB at 3 ft. (900mm) from blade
Laser Class 2, 3V 400~700 NM
Work light LED
Capacities and measurements
Blade speed 4000±10% RPM
Motor arbor size Ø 5/8 in. (15.875 mm)
Reducer for blade to arbor n/a
Ø 5/8 x 1 x 0.11 in.
(16 x 25.4 x 2.8 mm)
Saw blade
Ø10in. x 40T x 5/8in. arbor,
carbide tipped, (Ø254 x 15.875 x
2.8mm – 40T); Nmax. 7000 RPM
Ø12in. x 48T x 1in. arbor, carbide
tipped, (Ø305 x 25.4T x 2.8mm –
48T); Nmax. 7000 RPM
Blade arbor size 5/8 in. (15.875 mm) 1 in. (25.4 mm)
Miter cutting range 52° Left, 60° Right
Bevel cutting range 0° to 45° L & R
Miter stops 0, 15, 22.5, 31.6, 45 deg. L & R and 60 deg. R
Bevel stops 45° L, 0°, 45° R
Maximum sliding travel 9-3/8 in. (240 mm) 9.2 in. (233 mm)
Cutting capacity
See Table 2
Dust collection
Dust port diameter Ø 1-5/8 in. (40.6 mm)
Adaptor diameters Ø 1-5/8 in. (40.6 mm) to 2-1/2 in. (63 mm)
Main materials
Work table Aluminum
Base Aluminum
Extension support Aluminum
Upper blade guard Aluminum
Lower blade guard PC
Slide bar Steel
Upper sliding fence Aluminum
Lower fixed fence Aluminum
Dimensions
Machine overall dimensions, LxWxH
43-1/2 x 29-1/2 x 28-1/2 in.
(1100 x 750 x 720 mm)
47-1/2 x 30 x 30-5/8 in.
(1200 x 760 x 780 mm)
Shipping dimensions, LxWxH
37-3/8 x 24-7/8 x 14-1/2 in.
(950 x 630 x 370 mm)
41-3/4 x 26 x 17-3/8 in.
(1060 x 660 x 440 mm)
