9
Weights
Net weight (approx.) 47 lbs. (21 kg) 56 lbs. (25 kg)
Shipping weight (approx.) 54 lbs. (24 kg) 62 lbs. (28 kg)
5.1 Cutting capacities
Table 2
JMS-10X JMS-12X
Type of cut Miter angle Bevel angle Capacity
Cross cut 0° 0° 12 x 3-9/16 in. (305 x 90 mm) 14 x 4.0 in. (355 x 100 mm)
Miter cut 45° L & R 0° 8-1/2 x 3-9/16 in. (215 x 90 mm) 10 x 4.0 in. (254 x 100 mm)
Bevel cut 0° 45° L 12 x 1-9/16 in. (305 x 40 mm) 14 x 2.0 in. (355 x 50 mm)
Bevel cut 0° 45° R 12 x 1.0 in. (305 x 25 mm) 14 x 1-3/8 in. (355 x 35 mm)
Compound 45° L & R 45° L 8-1/2 x 1-9/16 in. (215 x 40 mm) 10 x 2.0 in. (254 x 50 mm)
Compound
45° L & R
45° R
8-1/2 x 1.0 in. (215 x 25 mm) 10 x 1-3/8 in. (254 x 35 mm)
1
subject to local and national electrical codes.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
L = length, W = width, H = height
L & R = Left and Right
n/a = not applicable
The specifications in this manual were current at time of publication, but because of our policy of continuous
improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring
obligations.
