6
Specifications
Model Number.............................................................................................................................JWBS-12OS
Stock Number ...................................................................................................................................708901B
Cutting Capacity (height/in.).......................................................................................................................... 6
Cutting Capacity (width/in.) ...................................................................................................................11-7/8
*Minimum Blade Width (in.)........................................................................................................................ 1/8
*Maximum Blade Width (in.)....................................................................................................................... 1/2
*Blade Length (in.) ...................................................................................................................................... 82
Blade Speed (SFPM) .............................................................................................................................. 2750
Table Size (in.) .................................................................................................................................... 14 x 14
Table Slot Size (DxW/in.) .................................................................................................................. 3/8 x 3/4
Table Height from Floor (in.) ................................................................................................................40-5/8”
Table Tilt..................................................................................................................................45º right, 5º left
Dust Chute Diameter................................................................................................................ 2”OD & 4” OD
Overall Dimensions (HxWxD/in.) ..............................................................................62-3/8 x 18-5/8 x 15-5/8
Motor ................................................................................................................................. 1/2 HP, 1Ph, 115V
Net Weight (lbs.) ........................................................................................................................132 (approx.)
Shipping Weight (lbs.) ................................................................................................................141 (approx.)
* The JWBS-12OS Band Saw comes equipped with a 1/4"x82"x20" blade (Part No. 709392) factory
installed.
Read and understand the entire contents of this manual before attempting
assembly or operation! Failure to comply may cause serious injury!
Unpacking
1. Remove all contents from the shipping
carton. Do not discard the carton or packing
material until the bandsaw is assembled and
is running satisfactorily.
2. Inspect the contents for shipping damage.
Report damage, if any, to your distributor.
The required hardware for all assembly on this
machine is found in the Hardware Bag for Stand
Assembly and Hardware Bag for Saw Body and
listed in the following page.
3. Compare the contents of the shipping carton
with the Shipping Contents on page 7.
Report shortages, if any, to your distributor.
Tools Required for Assembly
1 Accurate Straight Edge (approximately 2 ft)
1 Cross-point Screwdriver
1 4mm Hex Wrench (included)
1 5mm Hex Wrench
1 6mm Hex Wrench (included)
1 10mm Box Wrench
1 13mm Box Wrench
Note: Use of sockets and ratchets will speed
assembly time but are not required.
