4.1 Specifications for JWBS-15

Model number ...................................................................................... JWBS-15 ......................................... JWBS-15-3

Stock number .......................................................................................... 714600 ................................................ 714650

Band saw nominal size .............................................................................. 15 in. ................................................... 15 in.

Motor and electricals:

Motor type……………………………………………..totally-enclosed fan-cooled, induction, capacitor start .................

Horsepower ...................................................................................... 1.75 HP .................................................... 3 HP

Phase ................................................................................................... single .................................................. single

Voltage ................................................................ 115/230V (prewired 115V) ................................................... 230V

Cycle ...................................................................................................... 60Hz ................................................... 60Hz

Listed FLA (full load amps) ................................................................ 15/7.5A ..................................................... 12A

Starting amps........................................................................................... 75A ..................................................... 52A

Running amps (no load) ......................................................................... 5.1A .................................................... 2.4A

Start capacitor.................................................................... 300MFD 250VAC ................................ 300MFD 250VAC

Run capacitor........................................................................... 40μF 250VAC ..................................... 60μF 300VAC

Power transfer ............................................................................... poly v-belt ............................................poly v-belt

On/off switch ..................................................... push button with paddle stop .............. push button, magnetic starter

Motor speed .................................................................................. 1720 RPM ........................................... 1720 RPM

Power cord length ..................................................................... 6 ft. (183 cm) ....................................... 6 ft. (183 cm)

Power plug installed ............................................................................... 115V ................................................... 230V

Recommended circuit size

..................................................................... 20A ..................................................... 20A

Sound emission

…………………………………………………..75 dB at 40” (1000mm) from blade, without load .......

Capacities and speeds:

Wheel diameter ............................................................... 14-3/4 in. (375 mm) ............................. 14-3/4 in. (375 mm)

Resaw capacity (cutting height) ............................................ 14 in. (356 mm) ................................... 14 in. (356 mm)

Throat capacity ............................................................... 14-1/8 in. (359 mm) ............................. 14-1/8 in. (359 mm)

Maximum rip left of blade with fence ............................... 12-3/8 in. (316 mm) ............................. 12-3/8 in. (316 mm)

Maximum rip right of blade with fence ................................ 2-7/8 in. (73 mm) ................................. 2-7/8 in. (73 mm)

Blade length ................................................. 133 in. (min. 131.8; max. 133.5) ......... 133 in. (min. 131.8; max. 133.5)

Minimum blade width ........................................................................... 1/8 in. .................................................. 1/8 in.

Maximum blade width ............................................................................. 1 in. ..................................................... 1 in.

Blade speed ................................................................................... 3100 FPM ........................................... 3100 FPM

Blade provided ................................................. Hook, 1/2" x 0.0256 thk 6 TPI ............. Hook, 1/2" x 0.0256 thk 6 TPI

Main Materials:

Table .................................................................................... ground cast iron .................................. ground cast iron

Trunnion ........................................................................................... cast iron .............................................. cast iron

Frame ..................................................................................................... steel .................................................... steel

Band wheels ..................................................................................... cast iron .............................................. cast iron

Tires ................................................................................yellow polyurethane ............................ yellow polyurethane

Blade guides ................................................................................ ball bearing ......................................... ball bearing

Resaw fence .................................................................... extruded aluminum ............................. extruded aluminum

Paint finish ............................................................................. powder coating .................................... powder coating

Table, fence, miter gauge:

Table dimensions…………………………………………………………21-1/2 x 16 x 2 in. (546 x 406 x 51 mm) ...........

Table tilt .............................................................................. Left 5°, Right 45° ................................ Left 5°, Right 45°

Table height from floor .......................................................... 35 in. (889 mm) ................................... 35 in. (889 mm)

Miter T-slot .................................................................... 3/4 in. W x 0.35 in. H ........................... 3/4 in. W x 0.35 in. H

Resaw fence size LxWxH ..............................................18-1/8 x 1-3/4 x 6 in. ........................... 18-1/8 x 1-3/4 x 6 in.

Miter gauge angle ............................................................. Left 45°, Right 45° ............................... Left 45°, Right 45°

Fence fine adjust knob, travel per one revolution ............. 0.05 in. (1.25 mm) ............................... 0.05 in. (1.25 mm)

Fence fine adjust knob, maximum travel ............................... 0.35 in. (9 mm) .................................... 0.35 in. (9 mm)

Dimensions:

Footprint (base size), LxWxH……………………………………….25-1/2 x 21-5/8 x 2 in. (648 x 549 x 51 mm) ...........

Overall dimensions, LxWxH…………………………………………29-1/2 x 32 x 74 in. (750 x 812 x 1880 mm) ..........

Shipping package dimensions…………………………………....30 x 24-1/2 x 79-1/2 in. (760 x 625 x 2020 mm) .......

Dust collection:

Dust port outside diameter ................................................. 4 in. (100mm) x 2 ................................ 4 in. (100mm) x 2

Minimum extraction volume required .............................................. 400 CFM ............................................. 400 CFM

Weights:

Net ....................................................................................... 382 lbs (174 kg) .................................. 382 lbs (174 kg)

Shipping ............................................................................... 446 lbs (203 kg) .................................. 446 lbs (203 kg)

Subject to local/national electrical codes.

The specified values are emission levels and are not necessarily to be

seen as safe operating levels. As workplace conditions vary, this information is intended to allow the user to make a

better estimation of the hazards and risks involved only.
