5.0 Specifications
Table 1
Model number
JWP-13BT
Stock number 722130
Motor and electricals
Motor type DC, Series-wound
Horsepower 2 HP
Motor phase Single
Motor voltage 120 V
Cycle 60 Hz
Listed FLA (full load amps) 15 A
Motor speed 23,000 RPM
Starting current 13A
Running current (no load) 7.1A
On/off switch Toggle switch with removable safety key
Power cord 14AWG x 3C, 6-1/2 ft.
Power plug installed 5-15P (CSA/UL)
Recommended circuit and fuse/breaker size
1
20 A
Sound rating
2
97dB at 20 in. (508mm) from motor
Capacities
Maximum cutting width 13 in. (330 mm)
Maximum workpiece thickness 6 in. (153 mm)
Maximum cutting depth 1/8 in. (3.2 mm)
Maximum full-width depth of cut 1/16 in. (1.6 mm)
Minimum unbutted workpiece length 9-1/2 in. (240 mm)
Head movement per one revolution of handle 1/16 in. (1.6 mm)
Feed rate 18 and 26 FPM
Thickness gauge stops 1/8, 1/4, 3/8, 1/2, 3/4, 1 in.
Cutterhead and feed rollers
Number of cutterhead rows 6
Knife style Two-edged, HSS inserts
Knife inserts, number of 26
Knife inserts, size (LxW) 1-3/32 x 19/32 in. (28 x 15 mm)
Cutterhead speed, no load 10,000 RPM
Cutterhead diameter 2 in. (46 mm)
Dimensions
Dust chute diameter 4 in. (102 mm)
Overall dimensions, assembled (LxWxH) 28 x 22 x 19 in. (711 x 558 x 482 mm)
Main table size (LxW)
9-3/4 x 13 in. (248 x 330 mm)
Feed table size (LxW)
9-1/4 x 12-1/2 in. (227 x 318 mm)
Shipping box dimensions (LxWxH)
23 x 15-3/8 x 20-1/2 in. (585 x 390 x 520 mm)
Dust collection
Dust port outside diameter 4 in. (102 mm)
Recommended minimum dust extraction 500 CFM
Main materials
Main table and infeed/outfeed tables Steel
Frame Plastic
Feed rollers Rubber
Weights
Net weight 34 kg (74.8 lbs.)
Shipping weight 37.5 kg (81.7 lbs.)
