6
4.0 Specifications
Table 1
Stock number
722150 722155
Model number JWP-15B JWP-15BHH
Motor and Electricals
Motor type Totally enclosed, fan-cooled, induction, capacitor start
Horsepower 3 HP (2.2 kW)
Phase Single
Voltage 230 V only
Cycle 60 Hz
Listed FLA (full load amps)
11 A
Start capacitor 300MFD 125VAC
Run capacitor
60F 250VAC
Motor speed 3450 RPM
On/off switch Magnetic with LED illuminator, 14A overload protector
Power transfer
belt to cutterhead; gearbox/chain to feed rollers
Power cord 14AWG x 3C, 7 ft.
Power plug installed CSA/UL 6-15P
Recommended circuit size
1
15 A
Sound emission without load
2
98 dB at 20 in. (508mm) from
infeed table
83 dB at 20 in. (508mm) from
infeed table
Capacities
Maximum cutting width 15 in. (381 mm)
Maximum cutting thickness 6 in. (153 mm)
Maximum cutting depth 3/16 in. (4.7 mm)
Maximum full width depth of cut 1/8 in. (3.1 mm)
Minimum workpiece length 21-1/2 in. (540 mm)
Head movement per one revolution of handwheel 4 mm
Feed rate 16 and 20 FPM
Gearbox oil capacity 420 mL
Cutterhead and feed rollers
Number of cutterhead rows 3 4
Knife type Straight 4-sided knife inserts
Number of knives 3 48
Cutterhead speed 5200 RPM
Cutterhead diameter 2.6 in. (68 mm)
Main materials
Main table Cast iron
Extension tables Steel Cast iron
Cabinet Steel
Infeed roller Aluminum extrusion
Outfeed roller Rubber
Anti-kickback fingers Steel
Dust collection
Dust port diameter 4 in. (102 mm)
Recommended minimum dust collector capacity 600 CFM
Dimensions
Overall dimensions, assembled LxWxH
25.5 x 46.5 x 48 in. (648 x 1181 x 1219 mm)
Table size LxW
15 x 21.45 in. (381 x 545mm)
without in/out feed table
15 x 46.5 in. (381 x 1180mm)
with in/out feed table
15 x 21.45 in. (381 x 545mm)
without in/out feed table
15 x 49.2 in. (381 x 1250mm)
with in/out feed table
