COMPLEX RADIO CONTROL SYSTEM
Telemetry* -unidirectional communication is usable exclusively for
telemetry transmission, for instance with the US version of the
JETIBOX profi.
This setup change requires longer pressing (press and hold) of the left
or right push button. The receiver mode change is only accessible via
the JETIBOX, see the „Receiver setup“ chapter.
If you switch the receiver to „clone“ or „Telemetry“ modes, further
wireless setup communication becomes impossible because the
receiver is now communicating only unidirectionally. In order to
change the mode or setup, you have to connect the JETIBOX to the
receiver and make the desired change or switch the receiver back
to„Normal“ mode:
1. Insert BIND PLUG into the receiver socket labeled Ext.
2. Switch on the receiver
3. Switch on the transmitter
4. Execute the desired setup changes, see „Receiver setup“
* Setup valid only for US receivers (firmware version 3.11)
6.4 Out pin set
Setup of the physical receiver outputs.
Set Output pin - selection of output, which goes for the following
setup. The menu item shows, as a decimal number, the throw of the
selected output. Receiver output 1 is labeled as Y1.
EN
21
