Jeti spectraval 1501 User Manual

Operating Instructions
JETI spectroradiometer spectraval 15x1
Document Revision 105
6.2 Displaying of Results
Jog-Wheel
Reference
Settings
Browser Meas Button
Context
Target
Status bar
6.2.1 Numeric Values
This screen shows a list of measurements recorded after pressing the Measurement
button as demonstrated in the previous section.
6.2.1.1 Customizing the Num. Values List
The Numeric Values list can be customized with different units of measure (e.g.
Lv,xy,CCT) through the context-based Options, accessed from the Num. Values Screen.
Tap on the checkbox to select/deselect an item from the list and then return to the Num.
Value by tapping the Back Icon. Now your new data-set will display.
18 Copyright © 2017 JETI Technische Instrumente GmbH
