Connectors
Connector
Name
DCIN 12V DC–in Power Jack Connector
ATX2P Internal 12V System DC–in Power Connector
USB30 USB 3.0 Port Connector x2
DP Display Port Connector
LAN RJ-45 Gigabit LAN Port Connector
SATA1 SATAIII Port Connector
SATAPW SATA Power-out Connector
Headers
Header Name Description
FP_AUDIO Front Panel Audio Header 9-pin Block
FP_USB20 USB 2.0 Header 9-pin Block
COM1/COM2 Serial Port Header x2 9-pin Block
JW_FP Front Panel Header 9-pin Block
LAN_LED LAN Activity LED Header 2-pin Block
LVDS LVDS Header 30-pin Block
INVERTER LVDS Inverter Header 8-pin Block
Jumper
Jumper
Name Description
JP1 Pin (1&2): Clear CMOS RAM Function Setting
Pin (3&4): Reset all RTC register bits
Pin (5&6): Flash Descriptor Security Override
6-Pin Block
JP2 COM1 Header Pin9 Function Select 4-Pin Block
JP5 LVDS VCC 3.3V /5V/12V Select 4-Pin Block
JP6 INVERTER Backlight 5V/12V Select 3-Pin Block
AT_MODE
AT Mode Function Select 2-Pin Block
JP4 LVDS Panel Resolution Select 8-Pin Block
