JETWAY NP591 - Chapter 1 Introduction of the Motherboard; 1-1 Feature of Motherboard

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard

Onboard Intel
®
Braswell series SoC Processor, with low power consumption
never denies high performance

Onboard optional 2GB/4GB DDR3L 1600 MHz DRAM

Support 1 * SATAIII (6Gb/s) device

Onboard 1* full-size Mini-PCIE slot

Onboard 1* M.2 slot (M-key 2242 SATA interface for SSD device)

Integrated with 1 * 24-bit dual channel LVDS header

Support DP 1.1 output (Max. resolution 2560*1600@60Hz)

Support USB 3.0 data transport demand

Support CPU Over-Temperature protection

Support CPU Over-Current/Under Voltage protection

Support DRAM Over-Current/Under Voltage protection

Compliance with ErP standard

Support Watchdog function
