1-2 Specification
Spec Description
Design

Pico Form Factor;8-layer SBC;

PCB size: 100 mm x 72 mm
Embedded CPU

Intel
®
Braswell SoC CPU*
*CPU model varies from different IPC options. Please consult your
dealer for more information of onboard CPU.
Memory

Onboard optional 2GB/4GB un-buffered DDR3L 1600 MHz
DRAM
Expansion Slot

1* Full-size Mini-PCIE slot (MPE)
Storage

1* SATAIII port

1*M.2 M-key 2242 slot(M2)
LAN Chip

Integrated with Intel
®
i211AT PCI-E Gigabit LAN chip

Support Fast Ethernet LAN function of providing
10/100/1000Mbps Ethernet data transfer rate
Audio Chip

Realtek ALC662 2-CH HD Audio Codec integrated

Audio driver and utility included
BIOS

64Mbit Flash ROM
Rear I/O

1* 12V DC-in power jack

2* USB 3.0 port

1* Display port (HDMI port optional by order)

1* RJ-45 LAN port
Internal I/O

1* 2-Pin Internal 12V DC-in power connector

1* SATA Power-out connector

1* Front panel audio header

1* 9-pin USB 2.0 header (Expansible to 2* USB 2.0 ports)

2* Serial port header (COM1 support RS232/RS422/RS485)

1* Front panel header

1* LAN LED activity header

1* LVDS header

1* LVDS inverter
