26
FIF0].
ERP Function
The optional settings:[Disabled]; [Enabled].
This item should be set as [Disabled] if you wish to have all active wake-up
functions.
WatchDog Reset Timer
Use this item to enable or disable WDT reset function. When set as [Enabled], the
following sub-items shall appear:
WatchDog Reset Timer Value
User can set a value in the range of [10] to [255].
WatchDog Reset Timer Unit
The optional settings are: [Sec.]; [Min.].
WatchDog Wake-up Timer
This item support WDT wake-up.
The optional settings are: [Enabled]; [Disabled].
When set as [Enabled], the following sub-items shall appear:
WatchDog Wake-up Timer Value
User can select a value in the range of [10] to [4095] seconds when ‘WatchDog
Timer Unit’ set as [Sec]; or in the range of [1] to [4095] minutes when ‘WatchDog
Timer Unit ’ set as [Min].
WatchDog Wake-up Timer Unit
The optional settings are: [Sec.]; [Min.].
ATX Power Emulate AT Power
This item support Emulate AT power function, MB power On/Off control by power
supply. Use needs to select ‘AT or ATX Mode’ on MB jumper at first (refer to Page
10 , AT_MODE jumper for ATX Mode & AT Mode Select).
 Serial Port Console Redirection
*Note: ‘Serial Port Console Redirection’ is only optional for model NP591D4
series.
