4
Internal Diagram-Front Side:
*Note: Display port may be replaced by HDMI port option by customized order.
Onboard
2G/4GB
DRAM
RJ-45
LAN Port
Front Panel
Audio Header
USB 2.0 Headers
LVDS
Header
USB 3.0 Ports
SATA III Port
LVDS
INVERTER
*Display Port
12V DC-in
Power Jack
M.2
SATA Slot
Front Panel Header
AT_MODE
JP2
Internal12V Power
Connector
JP6
LANLED Header
SATA Power-out Connector
JP1
JP4
JP5
Full-size
Mini-PCIE Slot
COM2
Serial Port Header
COM1
Serial Port Header
