15
- Multi SSID: Device is broadcasting Main Wi-Fi and Secondary Wi-Fi. Selecting OFF
set the device to broadcast only Main Wi-Fi.
- Multi SSID Isolation: If On is selected, it prevents your devices from communicating
across the Main Wi-Fi and Secondary Wi-Fi access points.
- Wi-Fi Name: Service Set Identifier (SSID). This is the Wi-Fi network name your
router is broadcasting.
- Wi-Fi Password: The password needs to be at least 8 characters long.
- Wi-Fi Band: CG890 router supports both the 2.4 and 5GHz bands of Wi-Fi spectrum.
Choose Wi-Fi Band depends on your Wi-Fi client device capability. 5GHz normally
provides faster data speed than 2.4Ghz.
- Privacy Separator: If ON is selected, connected devices on the same Wi-Fi network
cannot make Local Area Network communication.
NOTE: if you connect WLAN printer to your CG890, Privacy Separator should be
OFF to send file from a connected device to the printer
- SSID Stealth: If ON is selected, the Wi-Fi name will not be broadcasted. You need to
manually enter the Wi-Fi name and the Password from your connected device to
connect.
- Authentication Method: The authentication methods are described below. Default is
WPA2/WPA3.
Authentication and encryption won't be performed.
There are risks that private info will be intercepted or
network will be used by unauthorized individuals.
- Encryption Method: Select an encryption method from the drop-down list.
NOTE: Changes to Authentication Method and Encryption Method could result in
loss of Wi-Fi connection depending on your connected devices’ Wi-Fi client security
capabilities. Consult with your connected devices’ user manuals before changing.
- Enable Guest Mode: Check this box to use the Secondary Wi-Fi as a Guest Wi-Fi
network. If checked, devices connected to this Secondary Wi-Fi network are not able
to access the Web Admin Home page
- Maximum Connections: Set the maximum number of the Wi-Fi connections Main and
Guest Wi-Fi network allow simultaneously.
