Note:
Observe the correct assembling position of the tail shaft parts.
The eyes (5) of the tube joints and the bar should be in the same direction,
according to the picture below.
Attention:
1- Failure in complying with minimum measures of tail shaft (see figure), can
cause its burst and throw parts to any direction.
2- The misalignment of the tail shaft will cause high level of vibration and the
shaft burst, which may cause serious injuries to the people nearby.
5
5
Greater than
L/3
L
