JFY tech JSI-1100TL - General Data

www.JFY-tech.com
24
Parameter
Model
JSI-1100TL
JSI-1500TL
Input Data
Max. DC power
1170W
1720W
Max. DC voltage
450V
450V
MPPT operating
voltage range
80V-450V
100V-450V
Number of
parallel inputs
1
1
Number of MPP
trackers
1
1
Max. input current
(total)
11.7A
10A
Output Data
Nominal AC output
power
1100W
1500W
Max. AC power
1100W
1650W
Max. output current
5.3A
7.9A
AC grid voltage range
198~264Vac
198~264Vac
AC grid frequency
range
47.01~50.49Hz
47.01~50.49Hz
Power factor (cos φ)
>0.99
>0.99
THDI(at nominal
output power)
<3% <3%
AC connection
Single phase
Single phase
Max. efficiency
96.4%
96.5%
Euro efficiency
95.4%
95.5%
MPPT efficiency
99.6 %
99.6 %
General Data
Dimensions (W /D/ H)
in mm
345/152/315
345/152/315
Weight
12Kg
12Kg
Operating
temperature range
–25 °C ~+60 °C
–25 °C ~+60 °C
