Parameter
Model
JSI-2000TL
JSI-2500TL
Input Data
Max. DC power
2300W
2620W
Max. DC voltage
500V
500V
MPPT operating
voltage range
100V-450V
100V-450V
Number of
parallel inputs
1
2
Number of MPP
trackers
1
1
Max. input current
(total)
13A
14.5A
Output Data
Nominal AC output
power
2000W
2500W
Max. AC power
2200W
2500W
Max. output current
10.5A
12.5A
AC grid voltage range
198~264Vac
198~264Vac
AC grid frequency
range
47.01~50.49Hz
47.01~50.49Hz
Power factor (cos φ)
>0.99
>0.99
THDI(at nominal
output power)
<3% <3%
AC connection
Single phase
Single phase
Max. efficiency
97%
97%
Euro efficiency
96.2%
96.1%
MPPT efficiency
99.6%
99.6%
General Data
Dimensions (W /D/ H)
in mm
345/152/355
345/152/355
Weight
13Kg
13Kg
Operating
temperature range
–25 °C ~+60 °C
–25 °C ~+60 °C
