Parameter
Model
JSI-3000TL
JSI-3600TL
Input Data
Max. DC power
3550W
3750W
Max. DC voltage
500V
500V
MPPT operating
voltage range
100V-450V
100V-450V
Number of
parallel inputs
2
2
Number of MPP
trackers
1
1
Max. input current
(total)
20A
21A
Output Data
Nominal AC output
power
3000W
3600W
Max. AC power
3400W
3600W
Max. output current
15.7A
16A
AC grid voltage range
198~264Vac
198~264Vac
AC grid frequency
range
47.01~50.49Hz
47.01~50.49Hz
Power factor (cos φ)
>0.99
>0.99
THDI(at nominal
output power)
<3%
<3%
AC connection
Single phase
Single phase
Max. efficiency
97.2%
97.3%
Euro efficiency
96.4%
96.5%
MPPT efficiency
99.6 %
99.6 %
General Data
Dimensions (W /D/ H)
in mm
345/152/385
345/152/385
Weight
15Kg
15Kg
Operating
temperature range
–25 °C ~+60 °C
–25 °C ~+60 °C
