www.JFY-tech.com
27
Parameter
Model
JSI-5000TL
JSI-6000TL
Input Data
Max. DC power
5200W
6250W
Max. DC voltage
550V
550V
MPPT operating
voltage range
100V-500V
100V-500V
Number of
parallel inputs
3
3
Number of MPP
trackers
1
1
Max. input current
(total)
22.5A
27.5A
Output Data
Nominal AC output
power
4600W
6000W
Max. AC power
5000W
6000W
Max. output current
24A
31.2A
AC grid voltage range
198~264Vac
198~264Vac
AC grid frequency
range
47.01~50.49Hz
47.01~50.49Hz
Power factor (cos φ)
>0.99
>0.99
THDI(at nominal
output power)
<3%
<3%
AC connection
Single phase
Single phase
Max. efficiency
97.6%
97.6%
Euro efficiency
97%
97.1%
MPPT efficiency
99.6 %
99.6 %
General Data
Dimensions (W /H/ D)
in mm
345/162/505
345/162/573
Weight
19Kg
24Kg
Operating
temperature range
–25 °C ~+60 °C
–25 °C ~+60 °C
