the packaging box of the machine in the way of wiring.
Step 2: power input connector will be inserted inverter "AC" IN port, and tighten. As
shown in the figure below:
1
2
3
4
Figure 6-3 ACIN connector terminal signal
Table 6-4 Description of connecting pins for water level sensors
Port (Sensor) connector pin
explain
Pin 1
S
Pin 2
T
Pin 3
PE
Pin 4
R
PE
N
L
Figure 6-4 ACIN connector line sequence nameplate schematic
