vision Snack Plus/Easy Combo // Vending
MNP86V03GBV00 Date: 2010/06/14 Rev. 0 PAGE 22 OF 62
4.14. BT-10 banknote reader
■ BT-10 MDB banknote reader
• 4 optical sensors explore the complete light spectrum.
• Magnetic sensor to check additional security features in euro banknotes.
• Standard MDB communication, pulses or serial (RS-232).
• Validates banknotes in any of four possible positions.
• Flash memory for easy program updating.
• Banknote patterns can be reprogrammed via a PC
• Operating temperature range: -10 to +60 °C
• MDB input voltage range: 20 ... 42 Vdc.
• Peak current 1 Amp.
• Power consumption at 32 V: Standby, 100 mA. Accepting banknotes, 320 mA
