John Bean EELR529A - Page 45

- 45 -
Parts Breakdown
ITEM#
PART#
Qty/Lift
DESCRIPTION
1
1-00288A
4
HEX NUT M8 GB/T 41-2000
2
EAM0156V22A
2
CABLE HEAD
3
EAA0485V07A
1
ROPE ASSEMBLY
4
EAH0075V27A
2
ADAPTER NPT-MALE 1/4-Ø6 POLY
5
EAH0075V25A
2
POLY TUBE Ø6
6
1-26488A
2
HEX BOLT M6X20 GB/T5783-2000
7
EAH0075V28A
2
HOSE CLAMPØ8
8
1-26288A
2
HEX NUT M6 GB/T6170-2000
9
EAH0075V26A
2
Ø6 – Ø8 STRAIGHT FITTING
10
EAH0075V29A
2
COIL POLY TUBE ASSEMBLY
11
EAM0156V12A
2
JB BLOCK PLATE
12
1-20488A
4
HEX SCREW GB/T 70.1-2008 M6X12
13
1-04488A
4
FLAT WASHER GB/T 848-2002 Ø6
14
1-04588A
4
SPRING WASHER GB/T 93-1987 Ø6
15
6-3896CN
1
PNEU T FITTING, 1/4" NPT F/F/M
16
1-10389A
1
TERMINAL BOLT
17
6-3010CN
2
90ELB PNEU 1/4NPT M-n10 F PUSH
18
1-25079A
2
NPT1/4 PLUG
19
EAH0075V04A
1
JACK BEAM AIR TUBE 10 mm-4740
20
6-3011CN
1
TEE n10 POLYTUBE PUSHLOCK
21
1-41680A
1
PLUG CONNECTION
22
EAH0058V16A
1
OIL-WATER SEPARATOR
23
40347
1
HOSE SLEEVE
24
EAA0485V16A
1
RELEASE VALVE ASSEMBLY
25
9-0675
2
SWIVEL ELBOW, 1/4" NYLON TUBE, 1/4 NPT-M
