1.0 Introduction
Congratulations on purchasing the “EHP System IV”
electric/air tire changer.
This tire changer is designed for ease of operation,
safe handling of rims, reliability and speed.
This combination of features means more pro! t and
added versatility for your shop, enabling you to work
with aluminium or magnesium alloy wheels without
damaging customer’s rims.
With a minimum of maintenance and care your tire
changer will provide many years of trouble-free
operation.
Please read this manual thoroughly before operating
the unit. Instructions on use, maintenance and
operational requirements of the machine are covered
in this manual.
STORE THIS MANUAL IN A SAFE PLACE FOR
FUTURE REFERENCE. READ THIS MANUAL
THOROUGHLY BEFORE USING THE MACHINE.
1.1 Nomenclature
Before installing and using the electric/air tire changer
it is suggested that you become familiar with the
nomenclature of the machine’s components (Fig.
1.1-1).
1 Vertical slide
2 Mounting arm, (horizontally displaceable)
3 Lock push-button
4 Handle
5 Mount/demount tool
6 Tower or column
7 Turntable
8 Clamping jaws (multi-position)
8a Air Jets
9 Bead breaker arm
10 Bead breaker blade
11 Bead breaker pad
12 Bead lifting tool
13 Foot pedal controls
14 Bead seater/in" ator pedal
15 In" ation gauge
ALL ELECTRICAL CONNECTIONS SHALL BE
PERFORMED BY A LICENCED TECHNICIAN.
ALL SERVICE MUST BE PERFORMED BY AN
AUTHORIZED SERVICE TECHNICIAN.
