32
4.1-6
4.1-7
4.1-8
NOTE:
ONCE TH E MOUNT/DEMOUNT HEAD IS
POSITIONED PROPERLY, IDENTICAL WHEELS
MAY BE CHANGED WITHOUT HAVING TO RESET
THE HEAD.
F. Insert the bead-lifting tool under the bead and
over the support of the mount/demount tool. Lift
the bead onto the mounting • nger. To facilitate this
operation, press with left hand on the bead in position
diametrically opposite to that of the tool. If desired, the
bead-lifting tool can be removed after lifting the bead
onto the • nger (Fig. 4.1-6).
G. Rotate the turntable clockwise and at the same time
push down on the tire sidewall to move the bead into
the drop-center of the rim (Fig. 4.1-7).
H. Repeat the process for removing the lower bead.
With left hand, lift the bead in position diametrically
opposite the tool to keep it in the drop center (Fig.
4.1-8). Move the swing arm aside and remove the tire.
