Network Control Module 300 Series Technical Bulletin 100
Table 33: Power Fail Test Results
Model NCM300-1 -2 NCM30
0 Notes
NCM350-1 -2 -8 NCM350
Notes
Memory
EPROM / SIMM 6.00 (-1)
EPROM / SIMM 6.02 (-2)
1 FLASH 8.01
SIMM 8.02
1
Battery
Status (LED)
Not Installed – LED on
Good–LED – off
Bad–LED on
2 Not Installed – LED on
Good – LED – off
Bad – LED on
2
Power Fail
(Good
Battery)
181 2 Power Fail** 3 181 2 Power Fail** 4
Power Fail
(Bad Battery)
181 0 Coldstart*
181 1 Warmstart*
5 181 0 Coldstart*
181 1 Warmstart*
6
Power Fail
(No Battery)
181 0 Coldstart*
181 1 Warmstart*
7 181 0 Coldstart*
181 1 Warmstart*
8
Software
Reset
181 3 Software
Reset*
9 181 3 Software Reset* 10
DRAM
(Battery
Backed)
Expand to 10 MBs using
SIMMs 2,4,6,10
Expand to 10 MBs using SIMMs
2,4,6,10
Since 12/98:
NCM350-8:
Notes: * Error log entries in the NCM error log
** New error log entries for Metasys Release 11.00
1. Verify latest EPROM revision.
2. Check the same data used by NCSETUP: good, bad, or missing. If the LED is lit, the battery is missing.
Verify using WNCSETUP information.
3. NCM300: power fail sequence: 181 2–means Power Fail with good battery, check battery status. After a
Power Fail, the NCM error log should contain the entry listed above. Other entries must be analyzed.
4. NCM350: Power Fail sequence: 181 2–means Power Fail with good battery, check battery status. After a
Power Fail, the NCM error log should contain the entry listed above. Other entries must be analyzed.
5. NCM300: Power Fail sequence: 181 0, 181 1–means Power Fail with bad or missing battery, check
battery status. After a Power Fail, the NCM error log should contain the sequence listed above. The 0
entry indicates a request for ‘data’ download because the DRAM is determined to be bad. Other entries
must be analyzed.
6. NCM350: Power Fail sequence: 181 0, 181 1–means Power Fail with bad or missing battery, check
battery status. After a Power Fail, the NCM error log should contain the sequence listed above. The 0
entry indicates a request for ‘data’ download because the DRAM is determined to be bad. Other entries
must be analyzed.
7. NCM300: Power Fail sequence: 181 0, 181 1–means Power Fail with bad or missing battery, check
battery status. After a Power Fail, the NCM error log should contain the sequence listed above. The 0
entry indicates a request for data download because the DRAM is determined to be bad. Other entries
must be analyzed.
8. NCM350: Power Fail sequence: 181 0, 181 1–means Power Fail with bad or missing battery, check
battery status. After a Power Fail, the NCM error log should contain the sequence listed above. The 0
entry indicates a request for data download because the DRAM is determined to be bad. Other entries
must be analyzed.
9. NCM300, manual reset: 181 3–After a manual reset, the NCM error log should contain the sequence
listed above. The 3 entry indicates a manual reset.
10. NCM350, manual reset: 181 3–After a manual reset, the NCM error log should contain the sequence
listed above. The 3 entry indicates a manual reset.
