Johnson Controls 5 J ZE Series User Manual

5742639-JIM-C-0220
Johnson Controls Ducted Systems 25
J03 through A6ZE - With Powered Convenience Outlet (Belt Drive High Static)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
J03
(3.0)
208-1-60
4
15.4 83.9 24 2.3 6.7 10
NONE - - - 38.3 50
E05 4 1 19.2 44.9 50
E07 5.6 1 26.9 54.5 60
E10 8 1 38.5 69 70
E15 11.9 2 57.2 92.4 100
E20 15.9 2 76.4 116.4 125
230-1-60
4
15.4 83.9 24 2.3 6.7 10
NONE - - - 38.3 50
E05 5.3 1 22.1 48.5 50
E07 7.5 1 31.2 59.9 60
E10 10.6 1 44.2 76.1 80
E15 15.9 2 66.2 103.7 110
E20 21.2 2 88.3 131.3 150
208-3-60 10.4 73 16.3 2.3 4.3 10
NONE - - - 29.6 40
E05 4 1 11.1 31.8 40
E07 5.6 1 15.5 37.3 40
E10 8 1 22.2 45.6 50
E15 11.9 2 33 59.2 60
E20 15.9 2 44.1 73 80
230-3-60 10.4 73 16.3 2.3 4.3 10
NONE - - - 29.6 40
E05 5.3 1 12.7 33.8 40
E07 7.5 1 18 40.4 45
E10 10.6 1 25.5 49.7 50
E15 15.9 2 38.2 65.7 70
E20 21.2 2 51 81.6 90
460-3-60 5.8 38 9 1.3 2.1 5
NONE - - - 15.6 20
E07 6.8 1 8.2 19.1 20
E10 10.1 1 12.1 24.1 25
E15 13.6 2 16.4 29.3 30
E20 19.5 2 23.5 38.2 40
575-3-60 4.2 36.5 5.9 1.3 1.9 4
NONE - - - 12.2 15
E10 10.6 1 10.2 20.1 25
E15 15.9 2 15.3 26.5 30
E20 21.2 2 20.4 32.9 35
J04
(4.0)
208-1-60
4
19.6 130 30.5 2.3 6.7 10
NONE - - - 43.5 60
E05 4 1 19.2 44.9 60
E07 5.6 1 26.9 54.5 60
E10 8 1 38.5 69 70
E15 11.9 2 57.2 92.4 100
E20 15.9 2 76.4 116.4 125
230-1-60
4
19.6 130 30.5 2.3 6.7 10
NONE - - - 43.5 60
E05 5.3 1 22.1 48.5 60
E07 7.5 1 31.2 59.9 60
E10 10.6 1 44.2 76.1 80
E15 15.9 2 66.2 103.7 110
E20 21.2 2 88.3 131.3 150
208-3-60 13.7 83.1 21.4 2.3 4.3 10
NONE - - - 33.7 45
E05 4 1 11.1 33.7 45
E07 5.6 1 15.5 37.3 45
E10 8 1 22.2 45.6 50
E15 11.9 2 33 59.2 60
E20 15.9 2 44.1 73 80
230-3-60 13.7 83.1 21.4 2.3 4.3 10
NONE - - - 33.7 45
E05 5.3 1 12.7 33.8 45
E07 7.5 1 18 40.4 45
E10 10.6 1 25.5 49.7 50
E15 15.9 2 38.2 65.7 70
E20 21.2 2 51 81.6 90
460-3-60 6.2 41 9.7 1.3 2.1 5
NONE - - - 16.1 20
E07 6.8 1 8.2 19.1 20
E10 10.1 1 12.1 24.1 25
E15 13.6 2 16.4 29.3 30
E20 19.5 2 23.5 38.2 40
575-3-60 4.8 33 7.5 1.3 1.9 4
NONE - - - 12.9 15
E10 10.6 1 10.2 20.1 25
E15 15.9 2 15.3 26.5 30
E20 21.2 2 20.4 32.9 35
