5742639-JIM-C-0220
26 Johnson Controls Ducted Systems
J05
(5.0)
208-3-60 16 110 24.9 4.4 6.8 10
NONE - - - 41.2 50
E05 4 1 11.1 41.2 50
E07 5.6 1 15.5 41.2 50
E10 8 1 22.2 48.8 50
E15 11.9 2 33 62.3 70
E20 15.9 2 44.1 76.2 80
E30 22.2 2 61.6 98 100
230-3-60 16 110 24.9 4.4 6.8 10
NONE - - - 41.2 50
E05 5.3 1 12.7 41.2 50
E07 7.5 1 18 43.6 50
E10 10.6 1 25.5 52.9 60
E15 15.9 2 38.2 68.8 70
E20 21.2 2 51 84.7 90
E30 29.6 2 71.2 110 125
460-3-60 7.8 52 12.1 4.4 3.15 5
NONE - - - 20.1 25
E07 6.8 1 8.2 20.4 25
E10 10.1 1 12.1 25.4 30
E15 13.6 2 16.4 30.6 35
E20 19.5 2 23.5 39.5 40
E30 28.8 2 34.6 53.5 60
575-3-60 5.7 38.9 8.9 4.4 2.2 4
NONE - - - 15.1 20
E10 10.6 1 10.2 20.5 25
E15 15.9 2 15.3 26.9 30
E20 21.2 2 20.4 33.2 35
E30 30.4 2 29.3 44.3 45
JA6
(6.0)
208-3-60 19.6 136 27 4.4 8.3 20
None - - - 47.2 60
E05 4 1 11.1 47.2 60
E07 5.6 1 15.5 47.2 60
E10 8 1 22.2 50.6 60
E15 11.9 1 33 64.1 70
E20 15.9 2 44.1 78 80
E30 22.2 2 61.6 99.9 100
230-3-60 19.6 136 27 4.4 8.3 20
None - - - 47.2 60
E05 5.3 1 12.7 47.2 60
E07 7.5 1 18 47.2 60
E10 10.6 1 25.5 54.8 60
E15 15.9 1 38.2 70.6 80
E20 21.2 2 51 86.6 90
E30 29.6 2 71.2 111.9 125
460-3-60 9.4 66.1 13 2.4 4.1 20
None - - - 23.3 30
E07 6.8 1 8.2 23.3 30
E10 10.1 1 12.1 26.5 30
E15 13.6 1 16.4 31.9 35
E20 19.5 2 23.5 40.8 45
E30 28.8 2 34.6 54.6 60
575-3-60 7.1 55.3 10 4.4 3.2 20
None - - - 17.9 25
E10 10.6 1 10.2 21.8 25
E15 15.9 1 15.3 28.1 30
E20 21.2 2 20.4 34.5 35
E30 30.4 2 29.3 45.6 50
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
4. Single phase, high static belt drive motors not available on gas heating units.
J03 through A6ZE - With Powered Convenience Outlet (Belt Drive High Static) (Continued)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
