279815-PTG-D-0408
10 Johnson Controls Unitary Products
TABLE 5: COOLING CAPACITIES - 3 TON (ACP036)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1000
77 45.2 2.8 21.4 17.8 14.2 - - - 43.9 3.0 21.0 17.2 13.5 - - -
72 43.3 2.7 27.6 24.0 20.4 16.7 - - 41.1 2.9 26.9 23.2 19.5 15.8 - -
67 41.4 2.5 33.7 30.1 26.5 22.9 19.3 - 38.3 2.8 32.9 29.1 25.4 21.7 18.0 -
62 38.0 2.4 38.0 36.7 31.8 28.2 24.6 21.0 34.9 2.7 34.9 34.3 30.6 26.9 23.2 19.5
57 35.6 2.5 35.6 35.6 35.2 31.6 28.0 24.4 33.4 2.7 33.4 33.4 33.1 29.4 25.6 21.9
1125
77 45.8 2.9 23.7 19.4 14.9 - - - 44.8 3.1 23.2 18.7 14.2 - - -
72 43.9 2.8 30.3 25.8 21.3 16.8 - - 41.9 3.0 29.4 25.0 20.5 16.0 - -
67 42.0 2.6 36.9 32.2 27.7 23.2 18.7 - 39.0 2.9 35.7 31.2 26.7 22.3 17.8 -
62 38.5 2.5 38.5 37.9 32.9 28.6 23.9 19.4 35.6 2.8 35.6 35.3 32.2 27.7 23.2 18.7
57 36.0 2.7 36.0 36.0 35.9 31.6 26.9 22.4 34.0 2.8 34.0 34.0 33.9 29.4 24.9 20.4
1250
77 46.4 3.1 26.0 21.0 15.6 - - - 45.6 3.1 25.4 20.2 14.9 - - -
72 44.5 2.9 33.1 27.7 22.3 16.9 - - 42.7 3.1 32.0 26.7 21.5 16.2 - -
67 42.5 2.7 40.2 34.4 29.0 23.6 18.1 - 39.7 3.0 38.5 33.3 28.0 22.8 17.6 -
62 39.1 2.6 39.1 39.1 34.0 29.0 23.2 17.8 36.3 2.8 36.3 36.3 33.7 28.5 23.2 18.0
57 36.5 2.8 36.5 36.5 36.5 31.7 25.7 20.3 34.6 2.9 34.6 34.6 34.6 29.4 24.1 18.9
1375
72 44.9 3.0 35.3 29.4 23.6 17.7 - - 43.1 3.1 34.2 28.4 22.7 16.9 - -
67 42.9 2.8 41.7 36.5 30.7 24.8 19.0 - 40.1 3.0 39.5 35.4 29.6 23.8 18.1 -
62 39.4 2.7 39.4 39.4 36.9 31.2 25.2 19.3 36.6 2.9 36.6 36.6 35.3 29.6 23.8 18.0
57 36.9 2.8 36.9 36.9 36.9 31.3 25.2 19.3 35.0 2.9 35.0 35.0 35.0 29.2 23.4 17.7
1500
72 45.2 3.0 37.4 31.2 24.9 18.6 - - 43.5 3.1 36.4 30.1 23.8 17.6 - -
67 43.3 2.8 43.3 38.6 32.4 26.1 19.8 - 40.5 3.1 40.5 37.4 31.1 24.8 18.5 -
62 39.7 2.7 39.7 39.7 39.7 33.4 27.2 20.9 36.9 2.9 36.9 36.9 36.9 30.6 24.4 18.1
57 37.2 2.9 37.2 37.2 37.2 30.9 24.6 18.3 35.3 3.0 35.3 35.3 35.3 29.0 22.7 16.4
95°F 105°F
1000
77 42.6 3.1 20.5 16.7 12.8 - - - 39.3 3.4 19.2 15.5 11.9 - - -
72 38.9 3.1 26.3 22.4 18.6 14.8 - - 35.7 3.3 24.7 21.1 17.4 13.8 - -
67 35.1 3.1 32.0 28.2 24.4 20.6 16.8 - 32.2 3.3 30.3 26.7 23.0 19.3 15.7 -
62 31.8 3.0 31.8 31.8 29.4 25.6 21.7 17.9 29.3 3.1 29.3 29.3 28.2 24.5 20.8 17.2
57 31.2 2.9 31.2 31.2 30.9 27.1 23.3 19.5 28.8 3.1 28.8 28.8 28.7 25.0 21.4 17.7
1125
77 43.7 3.2 22.6 18.0 13.6 - - - 40.2 3.4 23.0 17.1 12.6 - - -
72 39.9 3.2 28.6 24.1 19.7 15.2 - - 36.6 3.4 27.5 23.1 18.6 14.1 - -
67 36.0 3.2 34.5 30.2 25.8 21.3 16.9 - 33.0 3.4 32.0 29.0 24.5 20.1 15.6 -
62 32.7 3.0 32.7 32.7 31.4 26.8 22.5 18.1 29.9 3.2 29.9 29.9 29.4 24.8 20.4 16.0
57 31.9 3.0 31.9 31.9 31.8 27.1 22.9 18.5 29.5 3.2 29.5 29.5 29.4 24.8 20.5 16.0
1250
77 44.8 3.2 24.8 19.3 14.3 - - - 41.1 3.5 26.9 18.7 13.4 - - -
72 40.8 3.2 30.9 25.8 20.7 15.6 - - 37.4 3.5 30.3 25.0 19.7 14.5 - -
67 36.9 3.2 36.9 32.2 27.1 22.0 17.0 - 33.7 3.4 33.7 31.3 26.1 20.8 15.5 -
62 33.5 3.0 33.5 33.5 33.5 28.0 23.3 18.2 30.6 3.3 30.6 30.6 30.6 25.1 20.0 14.8
57 32.7 3.0 32.7 32.7 32.7 27.1 22.6 17.5 30.2 3.3 30.2 30.2 30.2 24.6 19.6 14.3
1375
72 41.3 3.3 33.1 27.4 21.8 16.1 - - 37.8 3.5 32.1 26.4 20.6 14.8 - -
67 37.3 3.3 37.3 34.2 28.5 22.8 17.1 - 34.0 3.5 34.0 32.5 27.2 21.4 15.6 -
62 33.8 3.1 33.8 33.8 33.8 27.9 22.4 16.7 30.9 3.3 30.9 30.9 30.9 25.1 19.4 13.6
57 33.1 3.0 33.1 33.1 33.1 27.1 21.7 16.0 30.5 3.3 30.5 30.5 30.5 24.6 18.9 13.2
1500
72 41.7 3.3 35.4 29.1 22.8 16.5 - - 38.1 3.6 33.9 27.7 21.4 15.2 - -
67 37.6 3.3 37.6 36.2 29.9 23.6 17.3 - 34.4 3.5 34.4 33.6 28.3 22.0 15.8 -
62 34.1 3.1 34.1 34.1 34.1 27.8 21.6 15.3 31.2 3.4 31.2 31.2 31.2 25.0 18.7 12.5
57 33.4 3.1 33.4 33.4 33.4 27.1 20.8 14.5 30.8 3.3 30.8 30.8 30.8 24.5 18.3 12.0
