TABLE 7: COOLING CAPACITIES - 4 TON (ACP048)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1200
77 59.1 3.2 26.7 22.4 18.1 - - - 56.5 3.6 26.6 22.1 17.7 - - -
72 54.6 3.1 34.2 29.9 25.6 21.2 - - 51.8 3.5 33.6 29.2 24.7 20.3 - -
67 50.1 3.1 41.7 37.4 33.0 28.7 24.4 - 47.1 3.5 40.7 36.2 31.8 27.3 22.9 -
62 46.0 3.1 46.0 44.8 38.6 34.3 30.0 25.7 42.7 3.5 42.7 42.1 37.7 33.2 28.8 24.3
57 44.7 3.5 44.7 44.7 44.7 40.4 36.0 31.7 41.1 3.4 41.1 41.1 41.1 36.7 32.2 27.8
1400
77 60.5 3.2 30.1 25.0 19.3 - - - 57.8 3.7 30.4 24.6 19.0 - - -
72 55.9 3.2 38.6 33.0 27.3 21.7 - - 53.0 3.6 37.7 32.1 26.5 21.0 - -
67 51.2 3.2 47.0 41.0 35.4 29.7 24.1 - 48.2 3.6 45.0 39.7 34.1 28.5 23.0 -
62 47.1 3.2 47.1 46.5 41.8 36.5 30.6 25.0 43.8 3.6 43.8 43.5 40.5 34.9 29.3 23.7
57 45.7 3.6 45.7 45.7 45.7 40.5 34.5 28.9 42.1 3.5 42.1 42.1 42.1 36.6 31.0 25.4
1600
77 61.9 3.3 33.6 27.5 20.6 - - - 59.2 3.8 34.2 27.0 20.3 - - -
72 57.2 3.3 43.0 36.1 29.1 22.2 - - 54.3 3.8 41.8 35.1 28.4 21.7 - -
67 52.4 3.3 52.4 44.6 37.7 30.7 23.8 - 49.4 3.7 49.4 43.2 36.5 29.7 23.0 -
62 48.1 3.3 48.1 48.1 45.0 38.6 31.2 24.2 44.8 3.7 44.8 44.8 43.2 36.5 29.8 23.1
57 46.8 3.7 46.8 46.8 46.8 40.6 32.9 26.0 43.1 3.6 43.1 43.1 43.1 36.4 29.7 23.0
1800
72 57.8 3.4 45.4 37.7 30.1 22.4 - - 54.9 3.8 44.4 36.9 29.3 21.8 - -
67 53.0 3.3 53.0 46.5 38.9 31.2 23.6 - 49.9 3.8 49.9 45.3 37.7 30.2 22.6 -
62 48.7 3.3 48.7 48.7 47.1 39.7 31.8 24.2 45.3 3.7 45.3 45.3 44.5 37.0 29.4 21.9
57 47.3 3.8 47.3 47.3 47.3 40.0 32.0 24.4 43.6 3.7 43.6 43.6 43.6 36.1 28.5 21.0
2000
72 58.4 3.4 47.8 39.4 31.0 22.7 - - 55.5 3.9 47.1 38.7 30.3 21.9 - -
67 53.6 3.4 53.6 48.5 40.1 31.8 23.4 - 50.5 3.8 50.5 47.3 38.9 30.6 22.2 -
62 49.2 3.4 49.2 49.2 49.2 40.8 32.5 24.1 45.8 3.8 45.8 45.8 45.8 37.5 29.1 20.7
57 47.8 3.9 47.8 47.8 47.8 39.5 31.1 22.7 44.1 3.7 44.1 44.1 44.1 35.8 27.4 19.0
95°F 105°F
1200
77 53.8 4.0 26.4 21.9 17.3 - - - 50.5 4.5 24.9 20.5 16.1 - - -
72 48.9 4.0 33.1 28.5 23.9 19.3 - - 45.6 4.5 31.3 26.9 22.5 18.1 - -
67 44.1 3.9 39.7 35.1 30.5 25.9 21.4 - 40.7 4.4 37.7 33.3 28.9 24.5 20.1 -
62 39.5 3.8 39.5 39.5 36.7 32.2 27.6 23.0 36.3 4.3 36.3 36.3 34.9 30.5 26.1 21.7
57 37.6 3.3 37.6 37.6 37.6 33.0 28.4 23.9 35.3 4.0 35.3 35.3 35.3 30.9 26.5 22.2
1400
77 55.1 4.1 30.7 24.2 18.6 - - - 51.7 4.6 30.8 23.0 17.4 - - -
72 50.2 4.1 36.8 31.3 25.7 20.2 - - 46.7 4.6 35.5 29.9 24.3 18.7 - -
67 45.2 4.0 43.0 38.4 32.9 27.3 21.8 - 41.7 4.5 40.2 36.8 31.3 25.7 20.1 -
62 40.5 4.0 40.5 40.5 39.1 33.3 28.0 22.5 37.2 4.5 37.2 37.2 36.5 30.8 25.3 19.8
57 38.5 3.4 38.5 38.5 38.5 32.7 27.5 21.9 36.2 4.1 36.2 36.2 36.2 30.5 25.1 19.5
1600
77 56.5 4.3 34.9 26.4 19.9 - - - 53.0 4.8 36.6 25.5 18.7 - - -
72 51.4 4.2 40.6 34.1 27.6 21.1 - - 47.8 4.7 39.7 32.9 26.1 19.4 - -
67 46.3 4.1 46.3 41.8 35.3 28.8 22.2 - 42.7 4.6 42.7 40.4 33.6 26.8 20.1 -
62 41.5 4.1 41.5 41.5 41.5 34.5 28.5 22.0 38.1 4.6 38.1 38.1 38.1 31.1 24.6 17.8
57 39.5 3.5 39.5 39.5 39.5 32.3 26.5 20.0 37.1 4.2 37.1 37.1 37.1 30.0 23.6 16.8
1800
72 52.0 4.3 43.5 36.0 28.6 21.1 - - 48.4 4.8 42.2 34.7 27.1 19.6 - -
67 46.9 4.2 46.9 44.0 36.5 29.1 21.6 - 43.2 4.7 43.2 41.7 34.8 27.3 19.7 -
62 42.0 4.2 42.0 42.0 42.0 34.3 27.1 19.6 38.5 4.6 38.5 38.5 38.5 30.9 23.4 15.9
57 40.0 3.6 40.0 40.0 40.0 32.2 25.1 17.6 37.5 4.3 37.5 37.5 37.5 29.8 22.4 14.9
2000
72 52.6 4.3 46.4 38.0 29.6 21.2 - - 49.0 4.8 44.8 36.4 28.1 19.7 - -
67 47.4 4.3 47.4 46.2 37.8 29.4 21.0 - 43.7 4.7 43.7 43.1 36.1 27.8 19.4 -
62 42.5 4.2 42.5 42.5 42.5 34.1 25.7 17.3 39.0 4.7 39.0 39.0 39.0 30.7 22.3 14.0
57 40.4 3.6 40.4 40.4 40.4 32.0 23.7 15.3 38.0 4.3 38.0 38.0 38.0 29.6 21.3 12.9
