279815-PTG-D-0408
Johnson Controls Unitary Products 15
115°F 125°F
1200
77 47.1 5.0 23.3 19.1 14.9 - - - 43.8 5.5 21.7 17.7 13.7 - - -
72 42.2 5.0 29.5 25.3 21.1 16.9 - - 38.8 5.5 27.7 23.7 19.7 15.7 - -
67 37.2 4.9 35.7 31.5 27.3 23.1 18.9 - 33.7 5.4 33.7 29.7 25.7 21.7 17.7 -
62 33.1 4.8 33.1 33.1 33.1 28.9 24.7 20.5 29.9 5.3 29.9 29.9 29.9 27.2 23.2 19.3
57 33.0 4.7 33.0 33.0 33.0 28.8 24.7 20.5 30.7 5.4 30.7 30.7 30.7 26.7 22.8 18.8
1400
77 48.3 5.1 30.9 21.8 16.2 - - - 44.9 5.6 31.0 20.6 15.0 - - -
72 43.2 5.1 34.1 28.5 22.9 17.3 - - 39.8 5.6 32.7 27.1 21.5 15.8 - -
67 38.1 5.0 37.4 35.2 29.6 24.0 18.4 - 34.6 5.5 34.5 33.6 28.0 22.3 16.7 -
62 33.9 4.9 33.9 33.9 33.9 28.3 22.7 17.1 30.6 5.4 30.6 30.6 30.6 25.8 20.0 14.4
57 33.9 4.8 33.9 33.9 33.9 28.2 22.6 17.0 31.5 5.5 31.5 31.5 31.5 26.0 20.2 14.6
1600
77 49.5 5.2 38.4 24.5 17.4 - - - 46.0 5.7 40.2 23.5 16.2 - - -
72 44.3 5.2 38.7 31.7 24.7 17.7 - - 40.7 5.7 37.8 30.5 23.2 15.9 - -
67 39.1 5.1 39.1 39.0 31.9 24.9 17.9 - 35.4 5.6 35.4 35.4 30.3 23.0 15.7 -
62 34.7 5.1 34.7 34.7 34.7 27.7 20.7 13.6 31.4 5.5 31.4 31.4 31.4 24.3 16.8 9.5
57 34.7 4.9 34.7 34.7 34.7 27.7 20.6 13.6 32.3 5.6 32.3 32.3 32.3 25.3 17.7 10.4
1800
72 44.8 5.2 41.0 33.3 25.6 18.0 - - 41.2 5.7 39.7 32.0 24.2 16.4 - -
67 39.5 5.2 39.5 39.5 33.2 25.5 17.9 - 35.9 5.7 35.9 35.9 31.5 23.7 16.0 -
62 35.1 5.1 35.1 35.1 35.1 27.5 19.8 12.2 31.7 5.6 31.7 31.7 31.7 24.1 16.2 8.4
57 35.1 5.0 35.1 35.1 35.1 27.4 19.8 12.1 32.7 5.6 32.7 32.7 32.7 25.1 17.1 9.4
2000
72 45.4 5.3 43.2 34.9 26.6 18.3 - - 41.7 5.8 41.6 33.4 25.1 16.9 - -
67 40.0 5.2 40.0 40.0 34.4 26.1 17.8 - 36.3 5.7 36.3 36.3 32.7 24.5 16.2 -
62 35.6 5.2 35.6 35.6 35.6 27.3 19.0 10.7 32.1 5.6 32.1 32.1 32.1 23.9 15.6 7.4
57 35.5 5.0 35.5 35.5 35.5 27.2 18.9 10.6 33.0 5.7 33.0 33.0 33.0 24.8 16.6 8.3
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
TABLE 7: COOLING CAPACITIES - 4 TON (ACP048) (CONTINUED)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
