279815-PTG-D-0408
8 Johnson Controls Unitary Products
TABLE 4: COOLING CAPACITIES - 2-1/2 TON (ACP030)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
750
77 33.1 2.0 14.8 12.2 9.6 - - - 32.4 2.3 14.8 12.0 9.2 - - -
72 32.5 2.1 19.9 17.3 14.7 12.1 - - 31.4 2.3 19.8 17.0 14.2 11.4 - -
67 31.9 2.2 25.0 22.4 19.8 17.2 14.7 - 30.3 2.3 24.9 22.1 19.3 16.5 13.7 -
62 31.1 2.0 31.0 28.5 25.9 23.3 20.8 18.2 29.0 2.2 29.0 27.7 24.9 22.1 19.3 16.5
57 31.0 2.0 31.0 30.4 27.9 25.3 22.7 20.2 29.1 2.2 29.1 28.8 26.0 23.2 20.4 17.6
875
77 33.3 2.0 15.2 12.8 10.0 - - - 32.7 2.3 15.9 12.7 9.6 - - -
72 32.7 2.1 21.0 18.2 15.3 12.5 - - 31.6 2.3 21.1 18.0 14.9 11.8 - -
67 32.1 2.2 26.7 23.5 20.6 17.8 15.0 - 30.6 2.3 26.4 23.3 20.2 17.1 14.0 -
62 31.3 2.0 31.2 30.0 27.0 24.4 21.3 18.5 29.3 2.2 29.3 28.6 26.1 23.0 19.8 16.7
57 31.2 2.0 31.2 30.9 29.1 26.6 23.4 20.6 29.3 2.2 29.3 29.2 27.3 24.1 21.0 17.9
1000
77 33.5 2.0 15.7 13.5 10.4 - - - 32.9 2.3 16.9 13.5 10.1 - - -
72 32.9 2.1 22.1 19.0 15.9 12.9 - - 31.8 2.3 22.4 19.0 15.6 12.2 - -
67 32.3 2.2 28.5 24.5 21.5 18.4 15.3 - 30.8 2.3 28.0 24.5 21.1 17.7 14.2 -
62 31.5 2.1 31.4 31.4 28.1 25.5 21.9 18.8 29.5 2.2 29.5 29.5 27.3 23.8 20.4 17.0
57 31.4 2.0 31.4 31.4 30.2 27.8 24.1 21.0 29.6 2.2 29.6 29.6 28.5 25.1 21.6 18.2
1125
72 33.2 2.1 23.1 19.8 16.6 13.3 - - 32.1 2.3 23.6 19.9 16.3 12.6 - -
67 32.5 2.2 30.3 25.5 22.3 19.1 15.8 - 31.0 2.4 28.9 25.7 22.1 18.4 14.7 -
62 31.8 2.1 31.6 31.6 29.8 26.8 23.3 20.1 29.7 2.2 29.7 29.7 28.5 24.8 21.2 17.5
57 31.6 2.0 31.6 31.6 31.0 28.1 24.5 21.3 29.8 2.2 29.8 29.8 29.2 25.6 21.9 18.3
1250
72 33.4 2.1 24.0 20.6 17.2 13.8 - - 32.3 2.3 24.8 20.9 17.0 13.1 - -
67 32.8 2.2 31.8 26.5 23.1 19.7 16.3 - 31.2 2.4 29.9 26.9 23.0 19.1 15.2 -
62 32.0 2.1 31.8 31.8 31.6 28.2 24.7 21.3 29.9 2.3 29.9 29.9 29.7 25.8 21.9 18.0
57 31.8 2.0 31.8 31.8 31.8 28.4 25.0 21.6 30.0 2.2 30.0 30.0 30.0 26.1 22.2 18.3
95°F 105°F
750
77 31.8 2.5 14.8 11.8 8.8 - - - 30.8 2.7 14.3 11.2 8.1 - - -
72 30.3 2.5 19.8 16.8 13.7 10.7 - - 28.8 2.6 19.1 15.9 12.8 9.7 - -
67 28.8 2.4 24.8 21.7 18.7 15.7 12.7 - 26.8 2.6 23.8 20.7 17.6 14.5 11.4 -
62 27.0 2.4 27.0 26.9 23.9 20.8 17.8 14.8 25.3 2.5 25.3 24.9 21.8 18.7 15.6 12.5
57 27.3 2.3 27.3 27.2 24.2 21.1 18.1 15.1 25.6 2.5 25.6 24.9 21.8 18.7 15.6 12.5
875
77 32.0 2.5 16.5 12.6 9.2 - - - 30.7 2.7 17.0 12.2 8.6 - - -
72 30.5 2.5 21.3 17.9 14.5 11.1 - - 28.7 2.7 20.7 17.2 13.7 10.1 - -
67 29.0 2.5 26.1 23.1 19.7 16.3 12.9 - 26.7 2.6 24.5 22.2 18.7 15.2 11.7 -
62 27.2 2.4 27.2 27.2 25.2 21.5 18.3 14.9 25.2 2.6 25.2 25.0 23.2 19.5 16.1 12.6
57 27.5 2.4 27.5 27.4 25.5 21.7 18.7 15.3 25.5 2.6 25.5 25.2 23.2 19.5 16.2 12.6
1000
77 32.3 2.5 18.2 13.5 9.7 - - - 30.5 2.8 19.6 13.2 9.1 - - -
72 30.8 2.5 22.8 19.0 15.2 11.5 - - 28.5 2.7 22.4 18.4 14.5 10.5 - -
67 29.2 2.5 27.4 24.5 20.7 17.0 13.2 - 26.6 2.7 25.1 23.7 19.8 15.9 11.9 -
62 27.4 2.4 27.4 27.4 26.4 22.1 18.9 15.1 25.1 2.6 25.1 25.1 24.5 20.3 16.6 12.7
57 27.7 2.4 27.7 27.7 26.8 22.3 19.2 15.4 25.4 2.6 25.4 25.4 24.6 20.3 16.7 12.7
1125
72 31.0 2.5 24.2 20.1 16.0 11.9 - - 28.4 2.7 23.6 20.0 15.3 10.9 - -
67 29.5 2.5 27.6 25.9 21.8 17.7 13.6 - 26.5 2.7 25.0 24.3 20.9 16.6 12.3 -
62 27.6 2.4 27.6 27.6 27.2 22.8 19.0 14.9 25.0 2.6 25.0 25.0 24.7 20.3 16.1 11.7
57 27.9 2.4 27.9 27.9 27.5 23.0 19.3 15.2 25.3 2.6 25.3 25.3 24.9 20.4 16.2 11.9
1250
72 31.2 2.6 25.5 21.2 16.8 12.4 - - 28.3 2.8 24.9 21.5 16.1 11.4 - -
67 29.7 2.6 27.9 27.2 22.9 18.5 14.1 - 26.4 2.7 24.9 24.9 22.0 17.3 12.6 -
62 27.9 2.5 27.9 27.9 27.9 23.5 19.1 14.7 24.9 2.7 24.9 24.9 24.9 20.2 15.5 10.8
57 28.1 2.4 28.1 28.1 28.1 23.8 19.4 15.0 25.2 2.7 25.2 25.2 25.2 20.5 15.8 11.1
To Next Page
