Johnson Controls ACPU024 THRU 060 User Manual

279815-PTG-D-0408
Johnson Controls Unitary Products 7
115°F 125°F
600
77 22.9 2.5 11.4 8.7 6.0 - - - 21.2 2.7 11.0 8.2 5.4 - - -
72 20.4 2.4 15.0 12.3 9.6 6.9 - - 18.1 2.6 14.4 11.6 8.8 6.0 - -
67 17.8 2.3 17.0 16.0 13.2 10.5 7.8 - 15.1 2.5 15.0 15.0 12.2 9.4 6.6 -
62 17.4 2.3 17.0 16.9 14.2 11.5 8.8 6.1 15.0 2.4 15.0 15.0 12.6 9.8 7.0 4.2
57 17.0 2.3 17.0 17.0 15.1 12.4 9.6 6.9 15.0 2.4 15.0 15.0 13.2 10.4 7.6 4.8
700
77 23.4 2.6 14.5 10.3 6.5 - - - 21.8 2.8 13.4 10.2 5.9 - - -
72 20.8 2.5 16.4 13.6 10.4 7.3 - - 18.7 2.6 15.3 12.9 9.7 6.4 - -
67 18.2 2.3 17.3 16.8 14.4 11.3 8.1 - 15.5 2.5 15.3 15.3 13.4 10.1 6.9 -
62 17.8 2.3 17.3 17.3 15.5 12.3 9.2 6.1 15.5 2.5 15.3 15.3 13.9 10.7 7.3 4.1
57 17.3 2.3 17.3 17.3 16.4 13.3 10.1 7.0 15.4 2.5 15.4 15.4 14.5 11.4 8.0 4.7
800
77 23.9 2.6 17.7 11.9 7.0 - - - 22.5 2.8 15.8 12.3 6.5 - - -
72 21.3 2.5 17.7 14.8 11.3 7.7 - - 19.2 2.7 15.8 14.3 10.5 6.8 - -
67 18.6 2.4 17.7 17.7 15.5 12.0 8.5 - 16.0 2.5 15.8 15.8 14.6 10.9 7.1 -
62 18.2 2.4 17.7 17.7 16.7 13.2 9.6 6.1 15.9 2.5 15.8 15.8 15.1 11.6 7.7 3.9
57 17.7 2.3 17.7 17.7 17.7 14.2 10.6 7.1 15.9 2.5 15.9 15.9 15.9 12.3 8.4 4.6
900
72 21.7 2.5 18.1 16.1 12.2 8.2 - - 19.8 2.7 16.3 15.7 11.5 7.3 - -
67 19.0 2.4 18.1 18.1 16.8 12.8 8.9 - 16.5 2.5 16.3 16.3 15.9 11.7 7.5 -
62 18.6 2.4 18.1 18.1 17.6 13.6 9.7 5.8 16.4 2.5 16.3 16.3 16.0 11.8 7.6 3.4
57 18.1 2.4 18.1 18.1 18.1 14.1 10.2 6.3 16.3 2.5 16.3 16.3 16.3 12.2 7.9 3.7
1000
72 22.2 2.5 18.5 17.4 13.1 8.7 - - 20.3 2.7 16.8 17.1 12.4 7.7 - -
67 19.4 2.4 18.5 18.5 18.0 13.7 9.3 - 16.9 2.6 16.8 16.8 16.8 12.1 7.9 -
62 19.0 2.4 18.5 18.5 18.5 14.1 9.8 5.5 16.9 2.6 16.8 16.8 16.8 12.1 7.5 2.8
57 18.5 2.4 18.5 18.5 18.5 14.1 9.8 5.5 16.8 2.5 16.8 16.8 16.8 12.1 7.5 2.8
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
TABLE 3: COOLING CAPACITIES - 2 TON (ACP024) (CONTINUED)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
