279815-PTG-D-0408
12 Johnson Controls Unitary Products
TABLE 6: COOLING CAPACITIES - 3-1/2 TON (ACP042)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1050
77 51.5 3.0 23.9 19.9 16.0 - - - 49.7 3.4 23.2 19.2 15.2 - - -
72 48.4 3.0 30.8 26.8 22.8 18.8 - - 46.3 3.3 29.9 25.9 21.9 17.8 - -
67 45.3 2.9 37.6 33.6 29.7 25.7 21.7 - 43.0 3.3 36.7 32.6 28.6 24.5 20.5 -
62 42.5 2.9 41.6 41.6 37.1 33.2 29.2 25.2 39.6 3.2 39.4 39.4 35.6 31.6 27.6 23.5
57 41.6 2.8 41.6 41.6 39.4 35.4 31.5 27.5 39.4 3.1 39.4 39.4 37.2 33.2 29.2 25.1
1175
77 51.7 3.0 24.1 20.6 16.2 - - - 49.9 3.4 24.4 19.9 15.4 - - -
72 48.6 3.0 31.9 27.6 23.2 18.8 - - 46.5 3.4 31.2 26.7 22.3 17.8 - -
67 45.5 2.9 39.2 34.5 30.2 25.8 21.4 - 43.1 3.3 38.0 33.6 29.1 24.7 20.2 -
62 42.6 2.9 41.8 41.8 37.7 33.6 29.0 24.6 39.8 3.2 39.6 39.6 36.3 31.9 27.4 22.9
57 41.8 2.8 41.8 41.8 40.1 36.0 31.3 26.9 39.6 3.2 39.6 39.6 38.0 33.5 29.0 24.6
1300
77 51.9 3.1 24.4 21.3 16.5 - - - 50.0 3.4 25.5 20.6 15.7 - - -
72 48.8 3.0 33.1 28.3 23.6 18.8 - - 46.7 3.4 32.5 27.6 22.7 17.8 - -
67 45.6 3.0 41.9 35.4 30.7 25.9 21.1 - 43.3 3.3 39.4 34.6 29.7 24.8 19.9 -
62 42.8 2.9 41.9 41.9 38.4 34.1 28.8 24.0 39.9 3.3 39.7 39.7 37.0 32.1 27.2 22.4
57 41.9 2.8 41.9 41.9 40.7 36.6 31.2 26.4 39.7 3.2 39.7 39.7 38.7 33.8 28.9 24.0
1400
72 49.1 3.1 34.3 29.3 24.4 19.4 - - 47.0 3.5 33.8 28.7 23.6 18.5 - -
67 45.9 3.0 42.7 36.6 31.7 26.7 21.7 - 43.6 3.4 40.0 35.9 30.8 25.7 20.6 -
62 43.0 3.0 42.2 42.2 40.2 35.5 30.3 25.3 40.2 3.3 40.0 40.0 38.4 33.3 28.2 23.1
57 42.2 2.9 42.2 42.2 41.6 37.0 31.7 26.7 40.0 3.3 40.0 40.0 39.5 34.4 29.3 24.2
1500
72 49.4 3.1 35.5 30.3 25.1 20.0 - - 47.3 3.5 35.1 29.8 24.4 19.1 - -
67 46.2 3.1 42.5 37.8 32.7 27.5 22.4 - 43.9 3.5 40.3 37.3 32.0 26.6 21.3 -
62 43.3 3.1 42.5 42.5 42.0 36.9 31.7 26.6 40.5 3.4 40.3 40.3 39.8 34.5 29.1 23.8
57 42.5 3.0 42.5 42.5 42.5 37.3 32.1 27.0 40.3 3.3 40.3 40.3 40.3 35.0 29.6 24.3
95°F 105°F
1050
77 47.9 3.8 22.6 18.4 14.3 - - - 45.4 4.2 21.5 17.3 13.1 - - -
72 44.2 3.7 29.1 25.0 20.9 16.8 - - 41.7 4.1 28.3 24.1 19.9 15.7 - -
67 40.6 3.6 35.7 31.6 27.5 23.4 19.3 - 37.9 4.0 34.4 30.8 26.6 22.4 18.2 -
62 36.7 3.5 36.7 36.7 34.1 30.0 25.9 21.8 34.4 3.9 34.4 34.4 32.6 28.4 24.2 20.0
57 37.2 3.5 37.2 37.2 35.1 31.0 26.9 22.8 35.0 3.9 35.0 35.0 33.4 29.2 25.0 20.8
1175
77 48.0 3.8 24.6 19.2 14.7 - - - 45.5 4.2 24.4 18.0 13.4 - - -
72 44.4 3.7 30.5 25.9 21.4 16.8 - - 41.8 4.1 29.6 24.9 20.3 15.7 - -
67 40.8 3.6 36.9 32.6 28.1 23.6 19.0 - 38.1 4.1 34.5 31.8 27.2 22.5 17.9 -
62 36.9 3.6 36.9 36.9 34.9 30.1 25.8 21.3 34.5 4.0 34.5 34.5 33.2 28.5 23.9 19.3
57 37.4 3.5 37.4 37.4 35.8 31.0 26.8 22.2 35.1 3.9 35.1 35.1 34.1 29.3 24.8 20.2
1300
77 48.2 3.8 26.6 20.0 15.0 - - - 45.7 4.3 27.3 18.8 13.7 - - -
72 44.6 3.8 31.8 26.8 21.8 16.9 - - 41.9 4.2 30.9 25.8 20.7 15.6 - -
67 40.9 3.7 37.0 33.7 28.7 23.7 18.7 - 38.2 4.1 34.6 32.8 27.7 22.7 17.6 -
62 37.0 3.6 37.0 37.0 35.6 30.2 25.7 20.7 34.6 4.0 34.6 34.6 33.9 28.6 23.7 18.6
57 37.5 3.5 37.5 37.5 36.6 31.0 26.7 21.7 35.2 4.0 35.2 35.2 34.8 29.4 24.6 19.5
1400
72 44.9 3.8 33.3 28.1 22.8 17.6 - - 42.2 4.2 32.3 26.9 21.6 16.2 - -
67 41.3 3.7 37.3 35.2 30.0 24.7 19.5 - 38.4 4.2 34.8 34.0 28.9 23.5 18.2 -
62 37.3 3.7 37.3 37.3 36.6 31.1 26.1 20.9 34.8 4.1 34.8 34.8 34.5 29.0 23.8 18.4
57 37.8 3.6 37.8 37.8 37.4 31.8 26.9 21.6 35.5 4.0 35.5 35.5 35.3 29.7 24.5 19.2
1500
72 45.3 3.9 34.8 29.3 23.8 18.2 - - 42.5 4.3 33.6 28.1 22.4 16.8 - -
67 41.6 3.8 37.6 36.7 31.2 25.7 20.2 - 38.7 4.2 35.1 35.1 30.0 24.4 18.8 -
62 37.6 3.7 37.6 37.6 37.6 32.1 26.6 21.1 35.1 4.1 35.1 35.1 35.1 29.4 23.8 18.2
57 38.1 3.7 38.1 38.1 38.1 32.6 27.1 21.6 35.7 4.1 35.7 35.7 35.7 30.1 24.4 18.8
