279815-PTG-D-0408
6 Johnson Controls Unitary Products
TABLE 3: COOLING CAPACITIES - 2 TON (ACP024)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
600
77 27.1 1.7 12.1 10.0 7.8 - - - 26.7 1.9 12.2 9.8 7.5 - - -
72 26.8 1.7 16.7 14.6 12.4 10.3 - - 25.8 1.9 16.5 14.2 11.8 9.5 - -
67 26.4 1.7 21.3 19.2 17.0 14.9 12.7 - 24.9 1.9 20.9 18.5 16.2 13.8 11.5 -
62 25.5 1.7 24.5 22.9 20.8 18.6 16.5 14.3 23.8 1.9 22.7 21.5 19.1 16.8 14.4 12.1
57 24.5 1.7 24.5 24.5 24.5 20.8 18.7 16.5 22.7 1.9 22.7 22.7 20.9 18.5 16.2 13.8
700
77 27.2 1.7 12.0 10.4 8.1 - - - 26.9 1.9 13.3 10.5 7.9 - - -
72 26.9 1.7 17.6 15.2 12.9 10.6 - - 26.0 1.9 17.6 15.0 12.4 9.9 - -
67 26.6 1.7 22.8 20.0 17.7 15.4 13.0 - 25.1 1.9 22.0 19.6 17.0 14.4 11.9 -
62 25.6 1.7 24.7 23.4 21.6 19.5 17.0 14.6 24.0 1.9 22.9 22.3 20.1 17.5 14.9 12.4
57 24.7 1.7 24.7 24.7 24.7 21.8 19.2 16.9 22.9 1.9 22.9 22.9 22.0 19.4 16.8 14.2
800
77 27.3 1.7 11.9 10.9 8.4 - - - 27.1 2.0 14.4 11.1 8.3 - - -
72 27.0 1.7 18.4 15.9 13.4 10.9 - - 26.2 1.9 18.7 15.9 13.1 10.2 - -
67 26.7 1.7 24.8 20.9 18.4 15.9 13.4 - 25.3 1.9 23.1 20.7 17.9 15.1 12.2 -
62 25.7 1.7 24.8 24.8 22.4 20.3 17.4 14.9 24.2 1.9 23.1 23.1 21.1 18.3 15.5 12.6
57 24.8 1.7 24.8 24.8 24.8 22.7 19.8 17.3 23.1 1.9 23.1 23.1 23.1 20.3 17.4 14.6
900
72 27.1 1.8 19.0 16.4 13.9 11.3 - - 26.4 2.0 19.7 16.7 13.7 10.7 - -
67 26.8 1.8 24.9 21.9 19.0 16.5 13.9 - 25.5 1.9 23.2 21.8 18.8 15.8 12.8 -
62 25.8 1.8 24.9 24.9 23.5 21.2 18.4 15.8 24.4 1.9 23.2 23.2 22.2 19.2 16.2 13.2
57 24.9 1.8 24.9 24.9 24.8 22.5 19.8 17.2 23.2 1.9 23.2 23.2 23.2 20.3 17.3 14.3
1000
72 27.2 1.8 19.6 17.0 14.4 11.7 - - 26.6 2.0 20.7 17.5 14.4 11.2 - -
67 26.9 1.8 25.0 23.8 19.7 17.1 14.4 - 25.7 2.0 23.4 22.8 19.7 16.5 13.3 -
62 25.9 1.8 25.0 25.0 24.6 22.0 19.4 16.7 24.5 1.9 23.4 23.4 23.2 20.1 16.9 13.8
57 25.0 1.8 25.0 25.0 25.0 22.3 19.7 17.1 23.4 1.9 23.4 23.4 23.4 20.3 17.1 14.0
95°F 105°F
600
77 26.3 2.1 12.2 9.7 7.1 - - - 24.6 2.3 11.8 9.2 6.5 - - -
72 24.9 2.1 16.3 13.8 11.2 8.7 - - 22.6 2.3 15.7 13.0 10.4 7.8 - -
67 23.4 2.0 20.4 17.9 15.3 12.8 10.2 - 20.6 2.2 18.7 16.9 14.3 11.6 9.0 -
62 22.2 2.0 20.9 20.0 17.4 14.9 12.4 9.8 19.8 2.2 19.0 18.5 15.8 13.2 10.6 7.9
57 20.9 2.0 20.9 20.9 18.8 16.3 13.7 11.2 19.0 2.1 19.0 19.0 16.9 14.3 11.7 9.1
700
77 26.6 2.2 14.5 10.5 7.6 - - - 25.0 2.4 14.5 10.4 7.0 - - -
72 25.1 2.1 17.7 14.8 12.0 9.1 - - 23.0 2.3 17.0 14.2 11.2 8.2 - -
67 23.7 2.1 21.2 19.2 16.4 13.5 10.7 - 21.0 2.2 19.3 18.0 15.4 12.4 9.4 -
62 22.4 2.0 21.2 21.2 18.6 15.6 12.9 10.1 20.1 2.2 19.3 19.0 17.1 14.0 11.1 8.1
57 21.2 2.0 21.2 21.2 20.1 17.1 14.4 11.5 19.3 2.2 19.3 19.3 18.2 15.2 12.3 9.3
800
77 26.9 2.2 16.8 11.3 8.1 - - - 25.4 2.4 17.2 11.6 7.6 - - -
72 25.4 2.1 19.1 15.9 12.8 9.6 - - 23.3 2.3 18.4 15.4 12.0 8.7 - -
67 23.9 2.1 21.4 20.6 17.4 14.3 11.1 - 21.3 2.2 19.6 19.1 16.5 13.1 9.8 -
62 22.7 2.1 21.4 21.4 19.8 16.3 13.5 10.3 20.4 2.2 19.6 19.6 18.3 14.7 11.6 8.2
57 21.4 2.0 21.4 21.4 21.4 17.9 15.1 11.9 19.6 2.2 19.6 19.6 19.6 16.0 12.8 9.5
900
72 25.7 2.1 20.4 17.0 13.6 10.1 - - 23.7 2.3 19.9 16.5 12.9 9.2 - -
67 24.2 2.1 21.6 21.6 18.5 15.1 11.7 - 21.6 2.2 19.9 19.9 17.6 14.0 10.3 -
62 22.9 2.1 21.6 21.6 20.8 17.2 14.0 10.6 20.7 2.2 19.9 19.9 19.2 15.4 11.9 8.2
57 21.6 2.1 21.6 21.6 21.6 18.0 14.8 11.4 19.9 2.2 19.9 19.9 19.9 16.1 12.5 8.8
1000
72 25.9 2.2 21.7 18.0 14.4 10.7 - - 24.1 2.3 20.2 17.7 13.7 9.7 - -
67 24.4 2.1 21.8 21.8 19.6 15.9 12.3 - 21.9 2.3 20.2 20.2 18.8 14.8 10.8 -
62 23.1 2.1 21.8 21.8 21.8 18.1 14.5 10.8 21.0 2.3 20.2 20.2 20.2 16.1 12.2 8.2
57 21.8 2.1 21.8 21.8 21.8 18.2 14.5 10.9 20.2 2.2 20.2 20.2 20.2 16.2 12.2 8.2
