Johnson Controls ACPU024 THRU 060 User Manual

279815-PTG-D-0408
22 Johnson Controls Unitary Products
FIGURE 3 - UNIT DIMENSIONS
HIGH VO L TAGE
CONN.
“ x " DIA.
KNOCKOUT
6
DRAIN
“ NPTI
CONDENS A TE
LOW VO L TAGE CONN.
“ DIA. KNOCKOUT
FRONT
CONDENSER
COIL
15
4
BACK
SIDE RETURN
AIR OPENING
SIDE SUPP L Y
AIR OPENING
BOT T OM RETURN
AIR OPENING
15
2
1
1
1
15
BOT T OM SUPP L Y
AIR OPENING
2
LOW VO L TAGE CONN.
“ DIA. KNOCKOUT
HIGH VO
L TAGE CONN.
" DIA. KNOCKOUT
FRONT
ELECTRICAL/FILTER
SE
R VICE ACCESS
COM
P A R TMEN T P ANEL
(OVERALL)
(OVERALL)
4
1
2
UNI T CONDENS A TE
CONNECTION
“ NPTI
(TRA
P REQUIRED)
(OVERALL)
SIDE SUPP
L Y
AIR OPENING
SIDE RETURN
AIR OPENING
COMPRESSOR
SE
R VICE ACCESS
COM
P A R TMEN T P ANEL
HIGH VO L TAGE CONN.
" DIA. KNOCKOUT
HIGH VO L TAGE CONN.
" DIA. KNOCKOUT
REFRIGERANT
CONNECTIONS
“A”
UNI
T SIZE
DIMENSION
“A”
0 24 - 042
33
048 - 060
41
CLEARANCES
(Minimum)
Fron t 12"
Bac
k 0"
Left Side (Filter Access ) 24"
Right Sid e 24"
Below Unit
1
0"
Above Unit
2
36" (For Condenser
Air Discharge)
1
Units may be installed on combustible floors made from wood or class A,
B or C roof covering material.
2
Units must be installed outdoors. Overhanging structures or shrubs
should not obstruct outdoor air discharge outlet.
