16 Addressable Intelligent Module—AIM-200 Addressable Intelligent Module

Branch Resistance

Short the termination point of one branch at a time and measure DC

resistance from the beginning of the loop to the end of that particular

branch. The total DC resistance from panel to branch end cannot exceed

40 ohms. Repeat this procedure for all remaining branches.

Figure 8: Non-Redundant Circuit Branch Resistance
