Addressable Intelligent Module—AIM-200 Addressable Intelligent Module 43
AIM-200 Point Annunciation
Note: For the following feature to be enabled, the AIM-200 requires
software Part No. 73264 or higher.
The CPU can be programmed for an alternate method of annunciating the
AIM-200. Up to 192 intelligent devices can be annunciated on a single
AIM-200 with ACM or LDM series annunciators, or the LCD-80 Liquid
Crystal Display on the RS-485 interface. The FC-2000 annunciates the
AIM-200 installed directly to the right of the CPU. Note that an
annunciator cannot be used to execute manual ON/OFF control of
intelligent AIM-200 points, only standard FC-2000 zones. The option
provides annunciation of up to 256 points for the FC-2000, broken down
as follows:
Figure 35: AIM-200 Point Location
