52 Addressable Intelligent Module—AIM-200 Addressable Intelligent Module
Control-by-Zone is suited for control-by-floor and floor above/floor below
applications. No special treatment is required to execute Control-by-Zone.
If the AIM-200 detects an alarm from an intelligent detector or addressable
monitor module, it activates which ever zone(s) are mapped to this device.
All M510CJ modules assigned to the alarmed zone(s) will be activated.
Table 10: Activating M510CJs Based on Zone Activity
Alarm
From
Detector or
M500MJ/M501MJ/
M502MJ Address
M510CJ
Address
Results
Detector or
Monitor
Module
01-99 01-99 M510CJ will be activated if not
mapped to the same zone as the
alarmed device.
Detector or
Monitor
Module
01-99 01-99 M510CJ will be activated if not
mapped to the same zone as the
alarmed device.
Control-by-Module is a useful function for Air Handling Units (AHUs)
controlled by 4-wire duct detectors. To set up Control-by-Module, set the
monitor module address in the range 60-69. Ensure that a M510CJ module
exists in the address range 70-79 with the same least significant address
digit as the M500MJ, M501MJ, M502MJ(s) and that the M510CJ module
has not been mapped to any zones.
Table 11: Activating M510CJs Based on Module Activity
Alarm
From
Monitor
Module
Address
M510CJ Address M510CJ Mapped
to Zone(s)?
Results
M500MJ,
M501MJ, or
M502MJ
60-69 70-79 No M510CJ will be activated if it
shares the same least significant
digit with the alarmed device and
is not mapped to any zones.
M500MJ,
M501MJ, or
M502MJ
60-69 70-79 Yes M510CJ will not be activated if
mapped to a zone.
M500MJ,
M501MJ, or
M502MJ
1-59,
70-99
** * M510CJ will not be activated if the
address of the alarmed device is
not within the range of 60-69.
* Result is the same whether M510CJ is mapped to any zone or not.
** Result is the same regardless of M510CJ address.
Control-by-
Zone
Control-by-
Module
