I/O terminal block functions, ratings, and requirements
Table 3: I/O terminal block functions, ratings, requirements, and cable guidelines
Terminal Block label Terminal
label
Function, ratings, requirements Determine wire size and
maximum cable length
+15 V 15 VDC Power Source for active (3-wire) input devices
connected to the Universal UI-n terminals.
Provides 100 mA total current
Same as (Universal) UI-n
Note: Use 3-wire cable for
devices that source power
from the +15V terminal.
Analog Input - Voltage Mode (0–10 VDC)
10 VDC maximum input voltage
Internal 10k ohm Pull-down
See Guideline A in Table 4
Analog Input - Current Mode (4–20 mA)
Internal 100 ohm load impedance
Note: Current loop jumpers must be in the Enabled
position to maintain a closed 4-20 mA current loop. See
Setting the UI current loop jumpers.
See Guideline B in Table 4.
Analog Input - Resistive Mode (0–600k ohm)
Internal 12 V. 15k ohm pull up
Qualified Sensors: 0-2k ohm potentiometer, RTD (1k Nickel
[Johnson Controls
®
sensor], 1k Platinum, and A99B Silicon
Temperature Sensor) Negative Temperature Coefficient (NTC)
Sensor
See Guideline A in Table 4.
UI-n
Binary Input - Dry Contact Maintained Mode
1 second minimum pulse width
Internal 12 V. 15k ohm pull up
See Guideline A in Table 4.
UNIVERSAL
(Inputs)
UI-C or UI-
Cn
Universal Input Common for all Universal Input terminals
Note: All Universal UI-C or UI-Cn terminals share a
common, which is isolated from all other commons.
Same as (Universal) UI-n
Binary Input - Dry Contact Maintained Mode
0.01 second minimum pulse width
Internal 18 V. 3k ohm pull up
BI-n
Binary Input - Pulse Counter/Accumulator Mode
0.01 second minimum pulse width
(50 Hz at 50% duty cycle)
Internal 18 V. 3k ohm pull up
BINARY
(Inputs)
BI-C or BI-
Cn
Binary Input Common for all Binary Input terminals
Note: All Binary BI-C or BI-Cn terminals share a
common, which is isolated from all other commons,
except the Configurable Output (CO) common when the
CO is defined as an Analog Output.
See Guideline A in Table 4.
Analog Output - Voltage Mode (0–10 VDC)
10 VDC maximum output voltage
10 mA maximum output current
Required an external load of 1,000 ohm or more.
See Guideline A in Table 4.CONFIGURABLE
(Outputs)
CO-n
Binary Output - 24 VAC Triac (External Power Source only)
Connects COn to CO-C or CO-Cn when activated.
External Power Source Requirements:
24 VAC maximum output voltage
0.5 A maximum output current
40 mA minimum load current
See Guideline C in Table 4.
F4-CG Series General Purpose Application Controllers Installation Guide8
