Table 3: Technical Specifications
Power Requirement 5.2 W
Power Consumption Typically 75 mA, maximum 100 mA.
1.2 W (nominal power without any loading on the SA Bus)
Power supply 11.3 VDC to 16.5 VDC
Ambient Conditions Operating: 0°C to 50°C (32°F to 122°F), 10% to 95% RH, Noncondensing
Storage: -40°C to 80°C (-40°F to 176°F), 5% to 95% RH, Noncondensing
Communications Protocol BACnet MS/TP
Communications Bus BACnet, RJ12 6-pin modular jack, 4-wire pluggable screw terminal block
Processor Renesas
®
RX651 32-bit Microcontroller
Memory 64 MB Flash memory and 32 MB SDRAM
Operating system Unison RTOS
Network and serial interfaces Communication to controller over SA Bus
Terminations SA Bus Port: RJ-12 6-pin modular jack
SA Bus Terminal: 4-wire pluggable screw terminal block
Mounting Mount to the outside of the enclosure, 85 mm x 160 mm (3.34 in. x 6.3 in.)
Housing Plastic housing material: ABS and polycarbonate
Protection IP20 (IEC60529)
Graphic Display Resolution 320 x 240 pixels with white LED backlighting (adjustable)
Dimensions (Height x Width x Depth) 85 mm x 160 mm x 27.5 mm (3.34 in. x 6.3 in. x 1.08 in.)
Weight 0.405 lb / 0.184 kg
Compliance United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management
Equipment
FCC Compliant to CFR47, Part 15, Subpart B, Class A
Canada: UL Listed, File E107041, CCN PAZX7 CAN/CSA C22.2 No. 205, Signal Equipment
Industry Canada Compliant, ICES-003
Europe: Johnson Controls declares that this product is in compliance with the essential
requirements and other relevant provisions of the EMC Directive and RoHS Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
United Kingdom: Johnson Controls declares that this product is in compliance with
Electromagnetic Compatibility Regulations, The Electrical Equipment (Safety) Regulations,
and Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment Regulations.
North American emissions
compliance
United States
This equipment has been tested and found to comply with
the limits for a Class A digital device pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
this equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area may cause harmful
interference, in which case the users will be required to
correct the interference at their own expense.
Warning (Part 15.21)
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
Canada
This Class (A) digital apparatus meets all the requirements
of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la Classe (A) respecte toutes
les exigences du Règlement sur le matériel brouilleur du
Canada.
Industry CanadaStatement(s)
F4-DLK0350 Product Bulletin4
