Johnson Controls FEC26 Series User Manual

Table 2: Termination Details
Termination DiagramsType of
Input/Output
Type of Field Device
UIFeedback from
EPP-1000
UI or BIDry Contact (Binary
Input)
CO or AO0–10 VDC Output to
Actuator (External
Source)
CO or AO0–10 VDC Output to
Actuator (Internal
Source)
CO or AO4–20 mA Output to
Actuator
9FEC26 Field Equipment Controllers Installation Instructions
