Johnson Controls FEC26 Series User Manual

FEC26 I/O Wiring Ratings and Requirements Table
The following table shows the input/output requirements and ratings for the FEC26 Series controllers.
Table 4: FEC26 Terminal Blocks, Functions, Ratings, Requirements, and Cables
Determine Wire Size and Maximum
Cable Length
Function, Ratings, RequirementsTerminal LabelTerminal Block
Label
Same as (Universal) INn
Note: Use 3-wire cable for devices that
source power from the +15V
terminal.
15 VDC Power Source for active (3-wire)
input devices connected to the Universal
INn terminals.
Provides 100 mA total current
+15 VUNIVERSAL
(Inputs)
See Guideline A in Table 5.
Analog Input - Voltage Mode (0–10
VDC)
10 VDC maximum input voltage
Internal 75k ohms Pull-down
INn
See Guideline B in Table 5.
Analog Input - Current Mode (4–20 mA)
Internal 100 ohms load impedance
Note: A current loop fail-safe jumper can
be positioned to maintain a closed
4 to 20 mA current loop, even
when the power to the controller
is interrupted or off. See the
Universal Input Current Loop
Jumpers section.
See Guideline A in Table 5.
Analog Input - Resistive Mode (0–600k
ohms)
Internal 12 V. 15k ohms pull up
Qualified Sensors: 0–2k ohms
potentiometer, RTD (1k Nickel [Johnson
Controls® sensor], 1k Platinum, and A99B
Silicon Temperature Sensor) Negative
Temperature Coefficient (NTC) Sensor
(10k Type L, 10k JCI Type II, 2.252k Type
II)
See Guideline A in Table 5.
Binary Input - Dry Contact Maintained
Mode
1 second minimum pulse width
Internal 12 V. 15k ohms pull up
Same as (Universal) INn
Universal Input Common for all Universal
Input terminals
Note: All Universal ICOMn terminals are
isolated from all other commons.
ICOMn
14FEC26 Field Equipment Controllers Installation Instructions
