FIRECLASS Fire detection system Binary DIP Switch Lookup Table
Installation Doc. version 2.0 47
Address defines the position of Zonal LED Panel on
the New X-BUS I2C interface. Up to four Zonal LED
Panels can be theoretically connected to the I2C
interface (the Part A and Part B addresses should be
the same).
Dimming causes the lower lightening intensity of
Zonal LED Panel. It can be set differentially for each
Part A and Part B.
18 Binary DIP Switch Lookup Table
Table 46 below shows the binary equivalents of decimal
numbers, with the binary most significant bit on the
right. Use this when setting slot cards addresses – for
example as detailed in Section “Install the PLX800 -
Loop Expansion Card”.
Item Function
X500 FC-FI interface connector
X501 Left FCNET / N-BUS (RS485) and
Power (24V) terminals
X502 Right MXNET / N-BUS (RS485) and
Power (24V) terminals
X503 Bypass Jumper for +24V*
X504 Bypass Jumper for GND*
X601 Ethernet interface connector
X602 Earth fast on connector
X1301 Swiss Firemen Interface connector
X1302 New X-BUS Interface connector (Zonal
LED Panel connection)
X1303 AC Repeater Panel Interface connec-
tor
[2]
Table 44: FC1DS - Jumper and terminal functions
* Fit these if there is more than one GUI supplied by the 24 V output.
[2] Powers the GUI from any 24V connection on the FC-FI board
Item Function
X1 Connector for interconnection with XP1
BB on FC-FI card
LED2 Alarm
LED4 Fault
LED5 System Fault
Table 45: BBI800 Connector and LED Functions
