Table 10: FX-PCG Technical Specifications
RS-485: selectable BACnet MS/TP or N2
3-wire FC bus between the supervisory controller and other controllers
4-wire SA bus between controller, network sensors and other sensor/actuator devices,
includes a lead to source 15 VDC supply power (from controller) to bus devices.
N2 Open Protocol:
N2/FC Bus: 1.5 mm (18 AWG) standard 3-wire, twisted, shielded cable recommended
between the supervisory controller and field controllers
Communications Bus
H8SX/166xR Renesas® 32-bit microcontrollerProcessor
640 KB flash memory and 128 KB RAMMemory
2 - Universal Inputs: Defined as 0-10 VDC, 4-20 mA, 0-600k ohm, or Binary Dry
Contact
2 - Binary Input: Defined as Dry Contact Maintained or Pulse Counter/Accumulator
Mode
3 - Binary Outputs: Defined as 24 VAC Triac (selectable internal or external source
power)
4 - Configurable Outputs: Defined as 0-10 VDC or 24 VAC/DC Field-Effect
Transistor (FET) BO
Input and Output Capabilities
Input: 16-bit resolution
Output: 16-bit resolution, +/- 200 mV accuracy in 0-10 VDC applications
Analog Input/Analog Output Resolution
and Accuracy
Input/Output: Fixed Screw Terminal Blocks
SA/FC Bus and Supply Power: 4-Wire and 3-Wire Pluggable Screw Terminal
Blocks
SA/FC Bus Port: RJ-12 6-Pin Modular Jacks
Terminations
Horizontal on single 35 mm DIN rail mount (preferred), or screw mount on flat surface
with three integral mounting clips on controller
Mounting
Enclosure material: ABS and polycarbonate UL94 5VB; Self-extinguishing, Plenum
Rated
Protection Class: IP20 (IEC529)
Housing
150 x 164 x 53 mm (5-7/8 x 6-1/2 x 2-1/8 in.) including terminals and mounting clips
Note: Mounting space requires an additional 50 mm (2 in.) space on top, bottom
and front face of controller for easy cover removal, ventilation and wire terminations.
Dimensions(Height x Width x Depth)
0.4 kg (0.9 lb)Weight
United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management
Equipment
FCC Compliant to CFR47, Part 15, Subpart B, Class A
Compliance
Canada: UL Listed, File E107041, CCN PAZX7 CAN/CSA C22.2 No.205, Signal
Equipment
Industry Canada Compliant, ICES-003
Europe: Johnson Controls, Inc. declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
BACnet International: BACnet Testing Laboratories (BTL) Protocol Revision 4
Listed BACnet Application Specific Controller (B-ASC)
24FX-PCG16 General Purpose Programmable Controller Installation Instructions
